GT-AR-2 | Greystone Energy Systems | Transducers
ANALOG TO TWO (2) RELAY MODULE
Brand:Greystone Energy Systems
MPN:GT-AR-2
SKU:GT-AR-2
List Price:
$368.00
Today's Price:
$191.36
product specifications
Mount
Snap-track
Output
Relay
Supply Voltage
23-30 VDC, 22-27 VAC
Type
Electronic
Output Signal
2 SPDT Form C Adjustable Relay
Input
Analog
Input Signal
0-7.5 VDC, 0-15 VDC, 0-20 mA
product series specifications
- Supply Voltage:
- 23-30 VDC, 22-27 VAC
- Supply Current:
- AR-2:
- 80 mA max. @ 24 VDC
- AR-4:
- 110 mA max. @ 24 VDC
- Input:
- 0-20 mA; 0-7.5 or 0-15 VDC
- Input Impedance:
- 250Ω
- Wiring Terminations:
- Screw terminal block 12-24 AWG
- Operating Temperature:
- 32° to 122‚Ñâ (0° to 50‚ÑÉ)
- Operating Humidity:
- 5 to 95% RH, non-condensing
- Enclosure:
- Snap track mounting; 3.9‚Ä=L x 3.3‚Ä=W x 1.3‚Ä=H (10 x 8.4 x 3.3 cm)
- Approvals:
- CE, RoHS
- Weight:
- AR-2:
- 0.24 lb (0.1 kg)
- AR-4:
- 0.3 lb (0.1 kg)
- Warranty:
- 5 years
product series features
- Two or four Form-C relay outputs
- Field-adjustable trip levels
- 3 jumper-selectable deadbands
- LED status indicator for each relay
- 3 jumper-selectable input ranges
- Regulated 20 VDC power output
- Compact and economical
- Snap track mounted
more information & related documents
Series Description
The Greystone Energy Systems GT-AR Series sequencer control module is a solid-state device used for multistage control in HVAC systems, sequencing boilers or chillers, or floating/tri-state control of VAV boxes from a single analog signal. The GT-AR Series can be used to obtain a digital output from a voltage or current producing sensor.
Kele Description
ANALOG TO TWO (2) RELAY MODULE
Manufacturer
Greystone Energy Systems
