1F85U-22PR | White-Rodgers | Thermostats & Controllers
Thermostat/Multi-2/2/Universal/Programmable
Brand:White-Rodgers
MPN:1F85U-22PR
SKU:1F85U-22PR
List Price:
$192.00
Today's Price:
$99.84
Log in for customized pricingproduct specifications
Controls Outputs
2H/2C
Type
Programmable
Display
LCD Backlit
Set Point Range
45 to 99 °F
Supply Voltage (Nominal)
24 VAC
product series specifications
Supply Voltage: 24VAC
Input Current: 0.05 to 1.0 Amp per terminal
Temperature Range: 32° to 105°F (0° to 41°C)
Setpoint Range: 45° to 99°F (7° to 37°C)
Schedule Type: 4 (Morning, Day, Evening, Night), 2 (Day and Night), 4 (Morning, Day, Evening, Night)
Operating Temperature: 32 to +105°F (0 to +41°C)
Materials Of Construction: ABS Plastic
Mounting: Any except upside down
Dimensions: See Catalog Page
Weight: 0.85 lbs, 0.65 lbs, 0.85 lbs, 1.05 lbs, 0.85 lbs
Warranty: 5 years
Accuracy: ±1°
Control Type: Low Voltage Thermostat
Differential: 1°
Display: Yes
Display Type: LCD
Enclosure: NEMA 1
Fan Switching: Yes
Storage Temperature: -4° to 150°F (-20° to 65°C)
System Type: Universal - SS, MS or HP
product series features
- Large 4 inch display
- Keypad lockout and setpoint temperature limit options
- Dual Power-Hardwired and/or battery powered
- Fits Horizontal or Vertical junction box
- Auto changeover option
more information & related documents
Series Description
The 1F80 Series thermostats are quickly configured for single stage or heat pump systems and can be selected as programmable or non-programmable. The 1F85 Series universal model thermostats are configurable for single stage, multistage, or heat pump. The ST models indicate that the models have a Spanish language display. These thermostats all offer the exclusive Cool Savings™ feature which adjusts the setpoint after 20 minutes to compensate for humidity loss thus providing the ultimate in comfort control and energy savings.
Kele Description
TSTAT/MULTI-2/2/ UNIVERSAL/ PROG
Manufacturer
White-Rodgers
Related Documents
White Rodgers Thermostat Reference Guide
