White wall thermostat with a green digital display and two round push buttons

SE7652H5045 | Viconics | Thermostats & Controllers

Heat Pump Controller: Stand Alone, 3H/2C, Local scheduling

Brand:Viconics

MPN:SE7652H5045

SKU:SE7652H5045

List Price:

$534.00

Today's Price:

$277.68

product datasheet

catalog page

Lead time of > 15 days. Chat with Kele experts now

product specifications

Type

Programmable

product series specifications

Supply Voltage: 20 to 30 VAC @ 2 VA, 50/60 Hz

Display Controls: Two-line backlit LCD,Five menu-driven buttons up, down, menu, no, yes/scroll

Thermostat Type: 7-day programmable and non-programmable models

Optimal Start: Progressive recovery enable/disable

Heat Pump High/Lo: Outside air lockout (emergency heating/compressor heating)

Stages Available: 1H/1C, 2H/2C, (3H/2C heat pump) 2H/2C + proportional mixed air economizer

Memory (Schedule): Permanent, EEPROM

Clock: Six-hour power-fail retention

System Switching: Off/Auto/Cool/Heat

Fan Switching: On-continuous; Auto-on demand; Smart-(on/occupied, off/unoccupied)

Control Accuracy: ±0.9°F (±0.5°C) at 70°F (21°C)

Setpoint Range

Heating: 40° to 90°F (4.5° to 32°C)

Cooling: 54° to 100°F (12° to 37.5°C)

Setpoint High/Low Limits: Individually adjustable heating / cooling

Remote Sensor

Room Sensor: Room sensor input auto-detected 10K Type 2 thermistors

Outside Air: Outside air input auto-detected 10K Type 2 thermistors

Mixed Air: Mixed air input auto-detected (economizer model only) 10K Type 2 thermistors

Ancillary Inputs: Two dry-contact digital inputs, applied for: Service/status reminders; Filter alarm; Night setback clock; Remote occupied override timer

Control Output: 1A relays, 30 VAC, SPST, 3A surge maximum

Auxiliary Contact Output: 1A relay, 30 VAC, SPDT, follows occupied schedule

Mixed Air Output: Proportional 0-10 VDC, 2KΩ minimum impedance (economizer model only)

Control Type: Proportional plus integral

Dead Band: Adjustable 2° to 4°F (1° to 2°C)

Outside Air Lockout Limits

Heating: 15° to 120°F (26° to 49°C), 5° increments

Cooling: -40° to 95°F (-40° to 35°C), 5° increments

Low Limit Protection: Enable/disable, heating on at 47°F (5.5°C)

Power-up Delay: Adjustable 10 to 120 seconds

Keypad Lockout: 3 levels, (full, none, partial)

Cycles Per Hour: Adjustable, heating 3-8; cooling, 3-4

Display Offset: Adjustable ±5°F (±2.5°C), 1°F increments

LED Indicators: Three green "on" (fan, cooling, heating)

Wiring: 18 AWG - 22 AWG

Mounting: Standard vertical 2"x 4" box

Color: White

Operating Temperature: 32° to 122°F (0° to 50°C)

Operating Humidity: 0 to 95% RH non-condensing

Enclosure Rating: NEMA 1, UL FR1 flame retardant plastic

Dimensions: 4.94"H x 3.38" x 1.13"D (12.5 x 8.6 x 2.9 cm)

Weight: 0.75 lb (0.34 Kg)

Approvals: UL File #E234137, CE, RoHs

Warranty: 1 year

product series features

ALL MODELS
Fan switching (on/auto/smart)
System switching (off/auto/cooling/heating)
Two line 8 digit backlit LCD Display
Three status LEDs (fan, cooling, heating)
Five control keys
Remote and outside air sensor inputs
Two configurable digital inputs
Fahrenheit or Celsius operation
Permanent program retention
Temporary setpoints
Proportional plus integral control
Cycles per hour for heating and cooling
Screen lockout (partial/total)
Power fail start up delay
H/C changeover (manual or auto)
Adjustable deadband
Individual setpoint range stops H/C
Extended fan run time
Extended occupancy time
Frost low limit protection
Outside air lockout H/C
No logo on thermostat
Room sensor calibration
Outside air calibration
PROGRAMMABLE MODELS
Two or four events per day
Progressive recovery or none
12 or 24 hour clock
Six-hour clock retention
Occupied/unoccupied output contact
ECONOMICAL MODELS
Mixed-air (0-10V) control output
Mixed-air sensor input
Mixed-air setpoint
Economizer changeover temp
Outside air damper minimum position (percent)
HEAT PUMP MODELS
Configurable heat pump O/B control
OSA lockout for HP emergency/comp heating

more information & related documents

Series Description

The Schneider Electric SE7600 Series is a digital display single or multistage 7-day programmable or non-programmable PI thermostat (F or C). It is used with AHU control and heat pump for both heating and cooling applications. The SE7600 has both system and fan switching with internal or remote sensor capabilities. Five buttons control a simple menu for setup of over 20 configurable parameters. Other control features are listed below.

Kele Description

T-STAT/3H/2C HEAT PUMP/PROG

Manufacturer

Viconics
