78671052077 | White-Rodgers | Thermostats & Controllers

Supply Voltage: 24VAC

Input Current: 0.05 to 1.0 Amp per terminal

Temperature Range: 32° to 105°F (0° to 41°C)

Setpoint Range: 45° to 99°F (7° to 37°C)

Schedule Type: 4 (Morning, Day, Evening, Night), 2 (Day and Night), 4 (Morning, Day, Evening, Night)

Operating Temperature: 32 to +105°F (0 to +41°C)

Materials Of Construction: ABS Plastic

Mounting: Any except upside down

Dimensions: See Catalog Page

Weight: 0.85 lbs, 0.65 lbs, 0.85 lbs, 1.05 lbs, 0.85 lbs

Warranty: 5 years

Accuracy: ±1°

Control Type: Low Voltage Thermostat

Differential: 1°

Display: Yes

Display Type: LCD

Enclosure: NEMA 1

Fan Switching: Yes

Storage Temperature: -4° to 150°F (-20° to 65°C)

System Type: Universal - SS, MS or HP
