VCM8000V5045P | Viconics | Thermostats & Controllers
COMMUNICATION MODULE ZIGBEE PRO FOR SE8000 SERIES
Brand:Viconics
MPN:VCM8000V5045P
SKU:VCM8000V5045P
List Price:
$346.00
Today's Price:
$179.92
product specifications
Type
Communicating
product series specifications
- Supply Voltage:
- 19-30 VAC, 50/60 Hz
- Supply VA:
- 6 VA
- Accuracy :
- Temperature, ±0.9‚Ñâ (±0.5‚ÑÉ)
- Digital Inputs:
- Dry contact
- Universal Input:
- Dry contact or 10K Type 2 Model 24 thermistor
- Display:
- Two line backlit LCD, ±0.2‚Ñâ (±0.1‚ÑÉ)
- Cover Controls:
- :
- Zone Models Up/down/override buttons
- :
- Heat/Cool “on” LEDs
- :
- FCU Models Up/down/‚ÑÉ-or-‚Ñâ/fan/mode buttons
- :
- Fan/Heat/Cool “on” LEDs
- Remote Sensor:
- Thermistor, 10K Type 2 Model 24
- Control Type:
- Proportional plus integral (PI)
- Cycles Per Hour:
- Adjustable
- Setpoint:
- Adjusted depending on heating or cooling mode, heating and cooling setpoints are changed simultaneously with respect to the deadband
- :
- Cooling limits 54° to 100‚Ñâ (12‚ÑÉ to 37.7‚ÑÉ)
- :
- Heating limits 40° to 90‚Ñâ (4.5° to 32‚ÑÉ)
- Keypad Lockout:
- Selectable system/fan/unoccupied
- System Setting:
- O=off, H=heating, C=cooling, A=automatic changeover
- Fan Setting:
- L=low, M=medium, H=high, A=auto
- Wiring:
- 16-24 AWG, 22 AWG recommended
- Color:
- White or Silver
- Mounting:
- Standard vertical, 2‚Ä= x 4‚Ä= box
- Operating Temperature:
- 32° to 122‚Ñâ (0° to 50‚ÑÉ)
- Operating Humidity:
- 0 to 95% RH (non-condensing)
- Enclosure Rating:
- UL FR1, flame retardant plastic
- Dimensions:
- 4.72‚Ä=H x 3.38‚Ä=W x 1.00‚Ä=D
- :
- (12.0 x 8.6 x 2.5 cm)
- Weight:
- 0.75 lb (0.34 kg)
- Approvals:
- UL Listed File #E234137, cULus, CE
- Warranty:
- 1 year
product series features
- Five (5) customizable colors for digital touch screens
- Supports the upload of a custom standby screen
- Supports the display of custom messages when integrated via BACnet MS/TP
- English, French, Spanish, Chinese, Russian and other selectable languages
- Interchange between degrees C/ degrees F
- BACnet MS/TP (default model)
- Zigbee Pro wireless mesh network (optional)
- Suitable for both commercial and hospitality markets and systems
- Humidity sensor with on-board dehumidification strategy (model dependent)
- Configurable fan sequence of operation
more information & related documents
Series Description
The Schneider Electric SE8350 Series offers fan coil room controllers so smart energy management has never been easier. Designed for new construction and retrofit projects, the room controllers dramatically decrease project delivery costs by reducing installation, configuration, and commissioning time. No complex software or tools are required to customize functionality in order to meet your application's requirements. The room controllers provide all the advanced features and monitoring functions required by modern building automation systems in a simple compact enclosure. The SE8350 Series are specifically designed to provide exceptional temperature control of multi-speed fan coil units. All models can provide advanced occupancy routines and automatic energy savings during occupied periods without sacrificing occupant comfort. When compared to traditional building automation controllers, the SE8350 Series fan coil room controllers provide unmatched return on investment. For more advanced needs, custom LUA script programming available. (-LS models) Kele is the leading supplier of building automation products. When you need the right product, right now, count on Kele.
Kele Description
COMMUNICATION MODULE ZIGBEE PRO FOR SE8000 SERIES
Manufacturer
Viconics
Related Documents
SE8000 Series Interface Guide 2014
SE8000 Series Sales Brocure-2014
SE8000 Series Zigbee Pro Integration Manual-2014
SE8300 Series Datasheet-2014
SE8300 Series Installation Guide-2014
SER8300 LINE VOLTAGE FAN COIL CONTROLLER - SPECIFICATION SHEET
TECHNICAL_CUT_SHEET_VT8300
