COV-PIR-FCU-C-5031 | Schneider Electric Buildings | Thermostats & Controllers
PIR COVER WITH COMMERCIAL
Manufacturer:Schneider Electric Buildings
MPN:COV-PIR-FCU-C-5031
SKU:COV-PIR-FCU-C-5031
List Price:
351.00
Today's Price:
196.56
add to cart
product family specifications
Supply Voltage
20-30 VAC, 50/60 Hz
Accuracy
±0.9°F (±0.5°C) @ 70°F (21°C)
Auxiliary Inputs
Two dry contact digital inputs
Four Types Service/status reminders
Filter alarm
Central night setback clock
Remote occupied override timer
Control Output
1A relays 30 VAC, 3A surge maximum
Auxillary Contact Output
1A relay 30 VAC, N.O./N.C. follows occupied schedule
Mixed Air Output
Proportional 0-10V DC, 2 kΩ minimum (economizer model)
Display
Two-line backlit LCD
Controls
Five menu-driven push buttons – up, down, menu, no, yes/scroll
Thermostat Type
Seven-day programmable models, non-programmable models
Optimal Start
Progressive recovery (enable/disable)
Heat Pump High/Low
OSA lockout (emer heating/comp. heating)
Stages
(Dependent upon model) 1H/1C, 2H/2C, (3H/2C heat pump) 2H/2C + proportional mixed-air economizer
Memory (schedule)
Permanent EEPROM
Clock (12 or 24 hour)
Six-hour power fail retention
System Switching
Off/Auto/Cool/Heat
Fan Switching
On-continuous
Auto-on demand
Smart-on/occupied, off/unoccupied
Setpoint Range
Heating 40° to 90°F (4.5° to 32°C)
Cooling 54° to 100°F (12° to 37.5°C)
Setpoint High/Low Limits
Individually adjustable, H/C
Remote Sensor
Room Sensor Room Sensor input auto-detected 10K Type 2 thermistors
Outside Air Outside air input auto-detected 10K Type 2 thermistors
Mixed Air Mixed air input auto-detected (economizer model only) 10K Type 2 thermistors
Control Type
Proportional plus integral
Deadband
Adjustable 2° to 4°F (1° to 2°C)
OSA Lockout Limits
Heating 15° to 120°F (26° to 49°C), 5°F increments
Cooling -40° to 95°F (-40° to 35°C), 5°F increments
Low Limit Protection
Enable/disable, heating @ 47°F (5.5°C)
Power Up Delay
10 to 120 seconds
Keypad Lockout
Three levels (full, none, partial)
Cycles Per Hour
Adjustable, heating 3-8 CPH, cooling 3-4 CPH
Display Offset
Adjustable ±5°F (2.5°C), 1°F increments
LED Indicators
Three green on (fan, cooling, heating)
Wiring
18 AWG max, 22 AWG recommended
Operating Temperature
32° to 122°F (0° to 50°C)
Operating Humidity
0% to 95% RH (non-condensing)
Color
White
Mounting
Standard vertical 2" x 4" box
Enclosure Rating
ULFR1 flame-retardant plastic
Dimensions
4.94"H x 3.38"W x 1.13"D
(12.5 x 8.6 x 2.9 cm)
Weight
0.75 lb (0.34 kg)
Approvals
UL, cUL, File #E234137, CE
Warranty
1 year
product family features
- ALL MODELS
- 1H/1C, 2H/2C (3H/2C heat pump) models
- Fan switching (on/auto/smart)
- System switching (O/A/C/H)
- Two line 8 digit backlit LCD Display
- Three status LEDs (Fan, Clg, Htg)
- Five control keys
- Remote sensor and OSA sensor inputs
- Adjustable deadband
- PIR cover available
- Permanent program retention
- Two configurable DI inputs
- Two line LCD display (°F or °C)
- Proportional + Integral control
- ECONOMIZER MODELS
- Mixed-air (0-10V) control outputs
- Mixed-air sensor input
- Mixed-air setpoint (SP)
- Economizer changeover S.P. temperature
- OSA damper minimum position in %
- PROGRAMMABLE MODELS
- Two or four configurable events per day
- Progressive recovery or none
- 12 or 24 hour clock
- Six hour clock retention
- Occ/Unocc auxiliary contact out
- COMMUNICATION MODELS
- BACnet
- LON
- Wireless
- Wireless/ Zigbee Pro
