KTP11K

KTP11K | Kele | Temperature Sensors & Transmitters

10,000Ω Flush-Mount Stainless Steel Plate Thermistor @ 77°F (25°C), Type III with 11K shunt (gray leads)

Brand:Kele

MPN:KTP11K

SKU:KTP11K

List Price:

$33.50

Today's Price:

$17.42



Availability: 6 In Stock
Available Inventory
These numbers are estimates based on our Memphis location and subject to change without notice based on customer demand.

Need more?
Just order your desired quantity and we'll ship the available inventory immediately while we source the remaining quantity to get you all the products you need as soon as possible.

We can also reserve the available inventory and ship once we acquire the remaining quantity from the supplier. Just choose "Ship Complete" at checkout.

product specifications

Accessory

T81U-XR, T85U-XR, T91U-XR, UR, DCP-1.5-W, DCPA-1.2, KT1

Application

Room Temperature, Classroom Temperature, Office Temperature, Washdown Environment

Housing Material

Metallic

Housing Rating

NEMA 1

Housing Style

Stainless Steel Plate

Output

Resistance

Probe Length

None

Sensor Element

10K Thermistor Type 3 with 11K Shunt

Setpoint

No

Type

Thermistor

Display

No

product series specifications

    Accuracy:
    Thermistor:
  • ±0.50‚Ñâ (0.28‚ÑÉ)
    RTD:
  • ±0.60‚Ñâ (0.33‚ÑÉ)
    Sensor Type:
    Thermistor:
  • 2.252 k‚Ѷ, 3 k‚Ѷ, 10 k‚Ѷ Type II, III & III w/11K shunt, 20 k‚Ѷ, 100 k‚Ѷ
    RTD:
    Type 71, 81:
  • 100‚Ѷ Pt 385 Curve
    Type 85:
  • 1000‚Ѷ Pt 385 Curve
    Type 91:
  • 1000‚Ѷ Pt 375 Curve
    Temperature Range:
    Thermistor/RTD:
  • -40° to 221‚Ñâ (-40° to 105‚ÑÉ)
    Temperature Coefficient:
    Thermistor:
  • Negative temperature coefficient
    RTD:
  • Positive temperature coefficient
    Temperature Stability:
    Thermistor:
  • 0.24‚Ñâ (0.13‚ÑÉ) over five years
    RTD:
  • Max 0.04% after 1k hours @ 500 ‚ÑÉ
    Heat Dissipation:
  • 2.7 mW/°C (power needed to raise the temperature 1°C)
    Enclosure rating:
  • NEMA 1, Brushed stainless steel
    Mounting:
  • Single gang back box
    Wiring Terminations:
  • 8' (2.4m) of 24 AWG gray wire leads,Type 71 & 81 sensors have 18" leads
    Weight:
  • 0.2 lb (0.10 Kg)
    Approvals:
  • CE
    Warranty:
  • 3 years

product series features

  • Three-year warranty
  • Wide selection of thermistor and RTD curves
  • Insulated backing for room temperature response
  • Vandal-resistant flush mounting
  • Adaptable with many options
  • 430 Stainless steel finish
  • Easy to mount to wall or back box
  • Standard size plate to cover mounting holes

more information & related documents

Series Description

The Kele KTP* Series Stainless Steel Flush-Mount Thermistor and RTD Sensors provide room temperature sensing for building automation systems. The active sensing element is made of a highly stable, thermistor material or platinum RTD. This design provides moisture/vapor resistance and is bonded to a 430 stainless steel plate. The back is insulated to reduce interior wall temperature influence. This sensor is intended for interior use only.

Kele Description

TEMP SENSOR, ROOM, 10K TYPE III (11K SHUNT), STAINLESS STEEL PLATE, NO SETPOINT, NO OVERRIDE
