T90PNR-2 | Kele | Temperature Sensors & Transmitters
XMTR 1K OHM 375 FIXED -20/140F
Brand:Kele
MPN:T90PNR-2
SKU:T90PNR-2
List Price:
$156.00
Today's Price:
$81.12
Log in for customized pricingproduct specifications
Type
RTD
Probe Length
None
Sensor Element
1K Platinum RTD 375
Output Signal
Analog
product series specifications
Supply Voltage: 10.5 - 45 VDC
Accuracy: 0.1% or 0.2% span
Signal Output: 4-20mA @ 675 Ω, loop-powered
Sensor Type: 1000 Ω platinum 375 curve, 1000 Ω platinum 385 curve, 100 Ω platinum 385 curve
Operating Temperature: 0° to 140°F (-18° to 60°C)
Operating Humidity: 0% to 95% non-condensing
Terminations: 6 or more leads
Mounting: Directly to wall or enclosure
Dimensions: 2.8" x 1.9" x 0.6" (7.1 x 4.8 x 1.4 cm)
Weight: 0.5 lb (0.2 Kg)
Warranty: 1 year
product series features
- Low cost
- Comes with handy box
- Easy to install
- Six preconfigured ranges
- Comes with 2 in x 4 in handibox (already installed)
- Potted Epoxy
more information & related documents
Series Description
The Kele T*PNR Series Temperature Transmitters are fixed range, two-wire 4-20mA transmitters used with Type 81, 85 and 91 series sensors. The transmitters are available in six standard ranges for temperature control and building automation. The Kele T81PNR Series is used with the Type 81 100 Ohm platium RTD sensor.The Kele T815NR Series is used with the Type 85 1000 Ohm 385 platium RTD sensor. The Kele T91PNR Series is used with the Type 91 1000 Ohm 375 platium RTD sensor.
Kele Description
XMTR 1K OHM 375 FIXED -20/140F
Manufacturer
Kele
