T5U-3 | Kele | Temperature Sensors & Transmitters
XMTR 1K OHM NI/FE 4-20MA (0/100)
Brand:Kele
MPN:T5U-3
SKU:T5U-3
List Price:
$314.00
Today's Price:
$163.28
Log in for customized pricingproduct specifications
Type
RTD
Probe Length
None
Sensor Element
1K Nickel RTD
Output Signal
Analog
product series specifications
Supply Voltage: 10.5-45 VDC
Accuracy: 0.2°F or 0.4% of span
Signal Output: 4-20 mA @ 675Ω, loop-powered
Sensor Element: 1000Ω Nickel RTD
Rangeability:
Zero: -30° to 210°F (-34.4° to 98.9°C)
Minimum Span: 40°F (22°C)
Usable Range: -30° to 250°F (-34.4° to 121.1°C)
Operating Temperature: 0° to 140°F (-18° to 60°C)
Operating Humidity: 0 to 90% non-condensing
Dimensions: 1.8"W x 2.25"L x 1"H (4.6 x 5.7 x 2.54 cm)
Weight: 0.16 lb (0.09 Kg)
Approval: CE
Warranty: 1 year
product series features
- Dip switch rangeable
- Loop calibration test signal
- Low cost
- Snap-track mounting
- Loop-powered LED indication
- Conformal coated
more information & related documents
Series Description
The Kele T5U and T63U Transmitters are field rangeable, two-wire 4-20 mA RTD transmitters designed for use with Type 5 nickel-iron sensors, the Precon Type 63 sensors, or the JCI TE6300 Series. Each one delivers reilable and accurate performance for a wide variety of applcations. This transmitter can be combined with any Type 63 Precon sensors incorporating the optional in.XW in. weather resistant box for a one package application solution. To adjust the temperature transmitter, set the DIP switches to match the desired range, and use the zero and span pots to fine tune. A high accuracy digital ohmmeter and decade box are required.
Kele Description
XMTR 1K OHM NI/FE 4-20MA (0/100)
Manufacturer
Kele
Related Documents
T5U Installation Sheet
