TSSOA14X | Greystone Energy Systems | Temperature Sensors & Transmitters

TEMP SENSOR, STRAP-ON, 10K TYPE III [11K SHUNT], 10.00" CLAMP, POLY ENCL

Brand:Greystone Energy Systems

MPN:TSSOA14X

SKU:TSSOA14X

List Price:

$102.00

Today's Price:

$53.04

Lead time of 8 days. Chat with Kele experts now

product specifications

Type

RTD

Probe Length

10 in

Sensor Element

10K Thermistor Type 3 with 11K Shunt

Housing

Polycarbonate

product series specifications

Sensor Type: Thermistor or RTD

Sensor Accuracy:

Thermistors: ±0.2°C (±0.36°F) @ 25°C (77°F)

Platinum RTDs: ±0.3°C (±0.54°F) @ 0°C (32°F)

Nickel RTDs: ±0.4°C (±0.72°F) @ 0°C (32°F)

Probe Sensing Range: -40 to 100°C (-40 to 212°F)

Ambient Operating Range: 0 to 50°C (32 to 122°F), 5 to 95 %RH non-condensing

Wire Material: PVC insulated, parallel bonded, 22 AWG

Wire Length: 1.524m (5')

Probe Material: 304 series stainless-steel

Probe Diameter: 6mm (0.236")

Enclosure:

A: ABS, UL94-V0, IP65 (NEMA 4X)

C: same as A, with a terminal block

E: Same as C, with thread adapter and cable gland fitting

Termination:

A: Pigtail, 2 or 3 wire

C & E: Terminal block, 2 or 3 wire

Country of Origin: Canada

Warranty: 5 years

product series features

Remote probe strap-on temperature sensors
Stainless-steel
PVC insulated
Available in various lengths

more information & related documents

Series Description

The Greystone TSRP and TSSO Series are single-point, remote probe strap-on temperature sensors that utilize a precision sensor encapsulated in a 6-mm (0.236 in) OD, 304 series stainless-steel probe. They are available in various lengths. Standard wire length is 1.5 m (5 ft). All probes are constructed to provide excellent heat transfer, fast response, and are potted to resist moisture penetration.

Kele Description

TEMP SENSOR, STRAP-ON, 10K TYPE III 11K SHUNT, 10.00" CLAMP, POLY ENCL

Manufacturer

Greystone Energy Systems
