THTDGA06 | Tasseron Sensors | Temperature Sensors & Transmitters
Q-Duct Box Temperature Sensor 10K type 2, 6” Probe, ip40
Brand:Tasseron Sensors
MPN:THTDGA06
SKU:THTDGA06
product specifications
Accessory
T81U-XR, T85U-XR, T91U-XR, UR
Feature
Quick Connect, Knockouts
Application
Air Handling Unit, Duct Temperature
Housing Material
Metallic
Housing Rating
NEMA 2, IP40
Output
Resistance
Probe Length
6 in
Sensor Element
10K Type 2 Thermistor
Type
Thermistor
product series specifications
Enclosure: NEMA 2/IP 40, 18 gauge / 1.2mm galvanized steel (NEMA 3S/IP 54 version on request) 1/2" knockout for wiring and fits optional watertight grommet
Cover: Dual slotted galvanized steel Quick Attach cover
Mounting: Integrated galvanized steel flange with two # 8 mounting holes
Probe Length: 4", 6", 8", 12", 18"
Probe Material: 6mm (± 1/4" AISI 316 stainless steel
Connection: 2-pole AWG 22-16, 0.35 - 1.5mm, 2 spring-loaded, Quick Connect wire terminals
Working Range: -40 to 125°C, -40 to 257°F
product series features
- Galvanized steel enclosure with Quick Attach cover
- Available in 4”, 6”, 8”, 12”, 18” lengths
- AISI 316 stainless steel temperature probe
- Quick Connect wire terminals eliminate wire nuts
- 1/2" port compatibale with watertight grommet
- Full anti-vibration pad on front of box
- NTC thermistors or RTD elements available
- Compatible with most major control systems
- Made in the USA
more information & related documents
Series Description
High quality universal Duct Temperature Sensor with galvanized steel enclosure and stainless steel AISI 316 probe for both commercial and industrial applications. Available measuring elements interface with most major control manufacturers. Accurate thermistors and RTD’s ensure low drift and are double encapsulated to guarantee the highest reliability. The dual-insulated, high quality, closed cell foam ensures sealing of the probe insert and absorption of vibrations. The dual-slotted, Quick Attach foamed cover and Quick Connect wire terminals make installations easy and reduce labor costs.<br>
Kele Description
TEMP SENSOR, DUCT, 10K TYPE II, 6.00" PROBE, METALLIC ENCL, NO OUTPUT
Manufacturer
Tasseron Sensors
