ST-D3-XHP

ST-D3-XHP | Kele | Temperature Sensors & Transmitters

Duct Temperature Sensor, 10K Type III Thermistor, Non-Metallic Handy Box Housing (Factory Installed)

Brand:Kele

MPN:ST-D3-XHP

SKU:ST-D3-XHP

List Price:

$59.00

Today's Price:

$30.68



Availability: Usually Ships in Less Than 6 Business Days
Available Inventory
Lead times are estimates based on our Memphis location and subject to change without notice based on customer demand.

Need more?
Just order your desired quantity and we'll ship the available inventory immediately while we source the remaining quantity to get you all the products you need as soon as possible.

We can also reserve the available inventory and ship once we acquire the remaining quantity from the supplier. Just choose "Ship Complete" at checkout.

product specifications

Accessory

T81U-XR, T85U-XR, T91U-XR, UR, F-100-331

Application

Duct Temperature, Air Handling Unit

Housing

Handy Box

Housing Material

Poly

Housing Rating

NEMA 1

Output

Resistance

Probe Length

9 in

Sensor Element

10K Type 3 Thermistor

Type

Thermistor

product series specifications

    Accuracy:
    Thermistor:
  • †±0.36‚Ñâ (0.2‚ÑÉ)
    RTD:
    Type 63:
  • †±0.72‚Ñâ (0.40‚ÑÉ)
    Type 71:
  • †+/-0.0774°F (0.043°C)

    Type 81, 85:
  • †±0.27‚Ñâ (0.15‚ÑÉ)
    Type 91:
  • †±0.54‚Ñâ (0.30‚ÑÉ)
    Sensor Type:
    Thermistor:
  • †2.252 k‚Ѷ, 3 k‚Ѷ, 10 k‚Ѷ Type II, III & III w/11K shunt, 20 k‚Ѷ, 100 k‚Ѷ
    RTD:
    Type 63:
  • †1000‚Ѷ Nickel
    Type 71, 81:
  • †100‚Ѷ Pt 385 Curve
    Type 85:
  • †1000‚Ѷ Pt 385 Curve
    Type 91:
  • †1000‚Ѷ Pt 375 Curve
    Temperature Range:
    Thermistor/RTD:
  • †-40° to 221‚Ñâ (-40° to 105‚ÑÉ)
    Temperature Coefficient:
    Thermistor:
  • †Negative temperature coefficient
    RTD:
  • †Positive temperature coefficient
    Temperature Stability:
    Thermistor:
  • †0.24‚Ñâ (0.13‚ÑÉ) over five years
    RTD:
  • †Max 0.04% after 1k hours @ 500 ‚ÑÉ
    Heat Dissipation:
  • †2.7 mW/‚ÑÉ (power needed to raise the temperature by 1‚ÑÉ)
    Enclosure Rating:
  • †Depends on the model
    Mounting:
  • †Directly to duct, wall, or single gang box
    Wiring Terminations:
  • †8' (2.4m) of 24 AWG pigtails with prestripped ends, type 71 & 81 sensors have 18" leads
    Weight:
  • †0.25 lb (0.1 Kg) with no options
    Approvals:
  • †CE
    Warranty:
  • †Lifetime

product series features

  • Lifetime warranty
  • Wide selection of thermistor and RTD curves
  • Tip sensitive for precise temperature response
  • Greenfield fitting standard

more information & related documents

Series Description

The PreCon Model ST-D* Duct Thermistor and RTD Sensor provides precision remote temperature sensing for building automation systems and mechanical equipment room instrumentation. The active sensing element is a highly stable precision thermistor material or platinum RTD. The sensing element is sealed with a thermally conductive compound in a 9 in (22.8 cm) long 304 stainless steel tube attached to a 4 in (10 cm) electrical strap. The slots in the mounting bracket form mounting ears for direct duct mounting and standard electrical boxes. The grommet on the tube fitting seals a 9/16 in (1.43 cm) insertion hole.

Kele Description

TEMP SENSOR, DUCT, 10K TYPE III, 9.00" PROBE, POLY ENCL

Manufacturer

Kele
