KTD21-XW | Kele | Temperature Sensors & Transmitters

Accuracy:

Thermistor: ±0°F (0.28°0.5C)

RTD: ±0.60°F (0.33°C)

Temperature Stability:

Thermistor: 0.24°F (0.13°C) over five years

RTD: Max 0.04% after 1k hours @ 500 °F

Heat Dissipation: 2.7 mW/°C (power needed to raise the temperature 1°C)

Sensor Type:

Thermistor: 2.252 kΩ, 3 kΩ, 10 kΩ, Type II, III & III w/11K shunt, 20 kΩ, 100 kΩ

RTD:

Type 71, 81: 100Ω Pt 385 Curve

Type 85: 1000Ω Pt 385 Curve

Type 91: 1000Ω Pt 375 Curve

Temperature Coefficient:

Thermistor: Negative temperature coefficient

RTD: Positive temperature coefficient

Temperature Range:

Thermistor/RTD: -40° to 221°F (-40° to 105°C)

Enclosure Rating: Depends on model

Mounting: Directly to duct, wall or single gang box

Wiring Terminations: 8' (2.4m), 24 AWG gray wire leads, type 71 & 81 sensors have 18" (0.45m) leads

Probe: Seamless 304 stainless steel tube, 1/4" OD

Weight:

KTD: 0.72 lb (0.33 Kg)

KTDNB: 0.2 lb (0.09 Kg)

Approvals: CE

Warranty: 3 years
