Small circular sensor body with a long clear tube coiled to one side.

TE-AAG-F1234-00 | Dwyer Instruments | Temperature Sensors & Transmitters

Temperature Averaging Sensor, General Purpose Housing, 20K Ohm Thermistor, 12 ft Probe, 3/8" Bendable Aluminum Probe, 4" Leads with Terminal Block, Reserved

Brand:Dwyer Instruments

MPN:TE-AAG-F1234-00

SKU:TE-AAG-F1234-00

List Price:

$-.--

Today's Price:

$-.--

product datasheet

product specifications

Averaging Type

Flexible

Type

Thermistor

Housing Material

Poly

Probe Length

12 ft

Sensor Element

20K Thermistor

Housing

Polycarbonate

Accessory

CC-1G-K,M-633,M-648-K,DCPA-1.2,691-K0A,DCP-1.5-W,UR,T81U-XR,T85U-XR,T91U-XR-GY,CC1-N,CC1-GY

Application

Duct Averaging Temperature,Air Handling Unit,Large Air Duct Temperature Monitoring

Output Signal

Resistance

product series specifications

Accuracy:Thermistor temperature sensor: ± 0.22°C @ 25°C (±0.4°F @ 77°F)

Temperature Limits: -40 to 302°F (-40 to 150°C)

Capillary Lengths: 6, 12, or 24' (depending on model)

Cable Length: 4"

Probe Material: Bendable aluminum probe

Housing Material: Meets UL, 94 V-0 polycarbonate plastic

Weight: 14 oz (397 g)

product series features

Easy to mount external tab housing
1/4 turn housing cover with chain
Multiple conduit knockouts for easy installation positioning

more information & related documents

Series Description

The TE-A Series averaging temperature sensor features a long, bendable aluminum capillary to measure the average temperature in large ducts and air handler units.

Kele Description

TEMP SENSOR, AVG, FLEXIBLE, 20K, 12.00' PROBE, POLY ENCL

Manufacturer

Dwyer Instruments
