BA/1K[375]-A-40'-BB | BAPI | Temperature Sensors & Transmitters

Accuracy:

Thermistor: ±0.36°F (0.2°C)

RTD: ±0.55°F (±0.30°C)

Sensor Type:

Thermistor: 10 kΩ Type II & III

RTD: 100Ω, 1000Ω, 385 curve; 1000Ω, 375 curve

Temperature Range: 32° to 158°F (0° to 70°C)

Stability: < 0.036°F (0.02°C) per year, 0.14°C with 6,000 continuous hours at 400°C

Heat Dissipation: 2.7 mW/°C (power need to raise the temperature 1°C), 0.4°C/mW at 0°C

Enclosure Rating:

NB: No box with 6 or more leads

JB: NEMA 1, 2 or more x 4 or more J-box with 1/2 or more knockouts

BB: NEMA 4, BAPI Box IP66 rated, NEMA 4 UV-resistant polycarbonate

BB2: NEMA 4, BAPI Box 2 IP66 rated, NEMA 4 UV-resistant polycarbonate

BB4: NEMA 3R, BAPI Box 4 IP44 Nylon & Plastic

WP: NEMA 3R cast aluminum

Mounting: Directly to Duct, with clips to mount coil

Wiring Terminations: 22 AWG wire, etched teflon leads

Weight: 1 to 2 lbs (Varies with probe length)

Approvals: CE, RoHS

Warranty: Lifetime
