DCP-250-P | Kele | Power Supplies
DC Power Supply, 120 VAC Input to 24 VDC Out, Panel/Surface Mount
Brand:Kele
MPN:DCP-250-P
SKU:DCP-250-P
List Price:
$179.31
Today's Price:
$93.24
Log in for customized pricingproduct specifications
VA Rating
10 VA
LCD
LED
Type
Enclosed Power Supply
Primary Voltage
120 VAC
Secondary Voltage
24 VDC
Application
Building Automation System,HVAC,BAS
Current Output
0.25 A
Mount
Panel,Surface
product series specifications
Supply Voltage: 110-125 VAC, 10 VA
Output Voltage: 24 VDC (regulated)
Supply Frequency: 50/60 Hz
Regulation: ±0.5V
Output Current: 250 mA
Mounting: DIN rail mount, Hub mount, Panel/surface mount
Temperature Stability: 1%
Operating Temperature: -22° to 104°F (-30° to 40°C)
Operating Humidity: 95% RH non-condensing
Dimensions: 4.0"H x 2.25"W x 1.75"D (10.16 x 5.71 x 4.45 cm)
Weight: 1.0 lb (0.5 Kg)
Approvals: UL916 File #E185225
Warranty: 1 year
product series features
- Flexible mounting for hub, panel/surface, DIN rail
- Compact size
- Fully enclosed
- Color-coded wiring
- LED indication
- Transformer isolated
more information & related documents
Series Description
The DCP-250 enclosed DC power supply from Kele is a unique DC power supply that provides regulated 24 volt DC power from a 120 volt AC input. It is well suited for powering transmitters, transducers, actuators, and other equipment in building automation systems, BAS, and temperature control applications. When ordering the DCP-250 specify hub mounting, surface mounting in a panel, or DIN rail mounting.
Kele Description
DC POWER SUPPLY, PANEL
Manufacturer
Kele
