ALT024-S-SW | Littelfuse | Relays & Contactors
Alternating Relay 24 VAC Override
Brand:Littelfuse
MPN:ALT024-S-SW
SKU:ALT-24-S-SW
List Price:
$323.00
Today's Price:
$167.96
Log in for customized pricingproduct specifications
Type
Alternating
Contact Type
SPDT
Number of Relays
1
Coil Voltage
24 VAC
Mount
Connection
product series specifications
Supply Voltage: 20-26 VAC/VDC, 95-125 VAC
Supply Current: 40 mA
Contact Rating: SPDT, 480 VA @ 240 VAC
Control Signal: 115 VAC, 2 mA, 24 VAC/VDC, 2 mA
Operating Temperature: -4° to 122°F (-20° to 50°C)
Debounce Time Delay: 0.5 sec
Approval: UL File E68520, CSA
Weight: 0.35 lb (0.16 Kg)
Warranty: 5 years
product series features
- Alternation between two loads to equalize run time
- Two LEDs to indicate the energized load
- Override switch
- Debounce time delay
more information & related documents
Series Description
The Model ALT alternating relay is commonly used to alternate between two loads to equalize run-time. When an external control switch opens, the Model ALT's output contacts transfer from one state to the other. When an external control switch closes, the output contacts remain in their current state. The SW option offers an override potentiometer switch on top of the relay that allows manual override control of either load or automatic operation.
Kele Description
ALT RELAY 24VAC OVERRIDE
Manufacturer
Littelfuse
Related Documents
Model-ALT
