Clear relay on black base with visible coil and contacts

20307-87 | Deltrol | Relays & Contactors

Plug-In Relay, 277 Vac Coil, 13 Amp DPDT

Brand:Deltrol

MPN:20307-87

SKU:20307-87

List Price:

$121.00

Today's Price:

$62.92

product datasheet

catalog page

product specifications

Type

General Purpose Plug-in

Contact Type

DPDT

Number of Relays

Contact Rating

13 A

Current Rating

13 A

Accessory

SR3B-05

Coil Voltage

277 VAC

Application

Industrial Machine Control,Control Panel,Energy Management

Mount

DIN rail,Surface

product series specifications

Coil Rating: 208 VAC @ 60 Hz, 277 VAC @ 60 Hz

Coil Power: 2.2 VA

Relay Type: DPDT (2 form C)

Relay Rating: 13A, 1/3 hp @ 120 VAC; 13A, 1/2 hp @ 277 VAC; 3A, 3/4 hp @ 600 VAC; 10A @ 28 VDC

Dimensions: 2.2"H x 1.5"W x 1.37”(5.6 x 3.8 x 3.5 cm)

Weight: 0.5 lb (0.23 Kg)

Approvals: UL File #E7443 File #E7443

Warranty: 1 year

NOTE: SR3B-05 socket is rated for 10A, 300 V max

product series features

208 VAC and 277 VAC coils
13A contact rating
UL recognized
Socket mounting
Heavy-duty construction

more information & related documents

Series Description

The Deltrol Controls 20307 Series plug-in style relays offer the flexibility of using 208 VAC or 277 VAC single-phase voltages for relay control. These relays are DPDT and plug into a standard three-pole general purpose relay socket.

Kele Description

277VAC COIL DPDT RELAY

Manufacturer

Deltrol
