VM-706
* product family image displayed

VM-706 | MAMAC Systems | Pressure

3-VALVE MANIFOLD

Manufacturer:MAMAC Systems

MPN:VM-706

SKU:VM-706

List Price:

616.86

Today's Price:

345.44



USD
Availability: Usually Ships in Less Than 5 Business Days
Available Inventory
Lead times are estimates based on our Memphis location and subject to change without notice based on customer demand.

Need more?
Just order your desired quantity and we'll ship the available inventory immediately while we source the remaining quantity to get you all the products you need as soon as possible.

We can also reserve the available inventory and ship once we acquire the remaining quantity from the supplier. Just choose "Ship Complete" at checkout.

add to cart

arrow

product family specifications

Supply Voltage

Current output

12-40 VDC @ 25 mA

Voltage output

12-40 VDC @ 10 mA, 12 to 35 VAC @ 0.3 VA

Accuracy

±1.0% Full scale (Linearity, Hysteresis, stability & Repeatability)

Signal Output (Volts,Current)

0-5V @ >1KΩ or 0-10V @ >1KΩ, 4-20mA @ <600Ω

Sensor Type

Piezoresistive silicon

Adjustments

Zero & Span trim POTs

Overpressure

(Burst) 300% of range

Max Operating Pressure

(Proof) 500% of range

Operating Temperature

0° to 180℉ (-18° to 82℃)

Compensated Temp Range

0° to 180℉ (-18° to 82℃)

Operating Humidity

10 to 90% Non-condensing

Wetted Parts

316 stainless steel

Media Compatibility

Liquid/Gasses compatible w/316 SS

Process Connection

1/8″ FNPT

Wiring Terminations

Removable Terminals 2-(4-20mA), 3-(volts), 12 AWG max

Mounting

Three Internal 0.188″ holes for #8 screws

Enclosure Rating

Painted steel 16 AWG, NEMA 1

Dimensions

5.88″W x 3.5″H x 2.0″D, (14.9 x 8.9 x 5.1 cm)

Weight

1.7 lb (0.75 Kg)

Approvals

CE, RoHS

Warranty

5 years

product family features

  • 100% solid state fused silicon pressure sensor
  • Rugged, leak-proof stainless steel monolithic pressure cavity with no welds, o-rings, or seams/bonds
  • NIST traceable calibration
  • Rugged NEMA-1 (IP-30) enclosure
  • Short circuit and reverse polarity protected
  • Conforms to EMC and RoHS standards

more information & related documents

Family Description

The MAMAC Systems Model PR282 Wet to Wet Differential Pressure Transmitter incorporates sophisticated integrated circuits and new fused silicon monolithic cavity pressure sensors to not only provide a high level, fully conditioned and temperature compensated output, but also to offer up to six (6) pressure ranges. The stainless steel monolithic pressure cavity not only provides media compatibility for most of the applications, but also offers a leakproof solution for today's environmentally conscious customers. Three industry standard output versions are available: 4-20 mA 2-wire loop or 0-5 VDC/0-10 VDC. A wide 12-40 VDC or 12-35 VAC unregulated supply voltage and a broad 0°F−180°F compensated temperature range ensures compatibility to most of the applications. A rugged NEMA-1 (IP-30) enclosure, fully temperature compensated NIST traceable accuracy and a liberal five year warranty are some of the features which make the Model PR282 the industry's most reliable, rugged, and economical pressure sensor.

Kele Description

3-VALVE MANIFOLD

Manufacturer

MAMAC Systems
