Long rectangular assembly with several black and white modules and connectors

DX5F0110STP1IW | Ashcroft, Inc | Pressure Components

DXLdp Series, ±0.50% of span, ±0.02% span T.C. /°F, 1/8" NPT Female, 0-10 Vdc-(12-36 Vdc), Screw Terminal, 0-0.10" WC

Brand:Ashcroft, Inc

MPN:DX5F0110STP1IW

SKU:DX5F0110STP1IW

List Price:

$-.--

Today's Price:

$-.--

product datasheet

installation instructions

catalog page

product specifications

Direction

Uni-Directional

Measurement

Inches of Water Column

Media Compatibility

Liquid,Gas

Range

±1 in WC

Type

Fixed

Accuracy

0.5%

Output

0 - 10 VDC

Supply Voltage (Nominal)

24 VDC

Mount

DIN rail

product series specifications

Supply Voltage: 12-36 VDC

Supply Current: < 10 mA for voltage

Accuracy: ±0.25%, ±0.5%, ±1.0%

Stability: ±0.25% FS/yr

Signal Output: 4-20 mA, 1-5 VDC, 1-6 VDC, 0-5 VDC, 0-10 VDC

Maximum Output:

Impedance mA: 545Ω @ 24 VDC

Maximum Pressure: 25 psi (172.4 kPa)

Burst Pressure: 25 psid (172 kPa)

Proof Pressure: 15 psid (103 kPa)

Response Time: 250 ms

Operating Temperature: -20° to 160°F (-28.9° to 71.1°C)

Operating Humidity: 10 to 95% RH (non-condensing)

Process Connection: 1/8" NPT

Media Compatibility: Clean, dry and non-corrosive gas

Enclosure Rating: NEMA 1

Dimensions: 3.9"W x 5.0"H x 0.9"D (9.9 x 12.7 x 2.3 cm)

Weight: 0.28 lb (0.13 Kg)

Approvals: CE

Warranty: 3 years

product series features

Reliable, repeatable and stable capacitive sensor
Ultra-low pressure ranges 0 to 0.10 in W.C. or ±0.05 in W.C.
DIN rail mount reduces installation and calibration costs
Easy access zero and span adjustments (optional)
0.25% and 0.50% include NIST certificate, option on 1.00% accuracy
CE Standard with all outputs
250ms response time
LED range status indicators

more information & related documents

Series Description

The Ashcroft DXLdp Series Differential Pressure Transmitters are designed for critical, high accuracy, low pressure applications. The DXLdp Series is available in accuracies of ±0.25%, ±0.50% and ±1.00% of Full Span which include non-linearity (Terminal Point Method) hysteresis, non-repeatability, zero offset, and span setting errors. It is available with voltage or milliamp outputs. The models are available in unidirectional and bidirectional ranges from 0.10 in W.C. to 50 in W.C. and ±0.05 in W.C. to ±25 in W.C. respectively.

Kele Description

AIR DIFF PRESS XMTR, FIXED, +/-0.50%, 0-0.10" WC, 0-10 VDC, NO LCD, DIN RAIL
