Stainless solenoid valve with black coil.

22WDP-532 | Belimo | Pressure Components

Differential Pressure Sensor Water, 0...30 psi, active, 4...20 mA

Brand:Belimo

MPN:22WDP-532

SKU:22WDP-532

List Price:

$1,143.00

Today's Price:

$594.36

product datasheet

installation instructions

Lead time of 7 days. Chat with Kele experts now

product specifications

Direction

Uni-Directional

Measurement

PSI

Media Compatibility

Liquid,Gas

Range

±50 psi

Type

Adjustable

Accuracy

0.5%

Output

4 - 20 mA

Enclosure Rating

NEMA 4

Approvals

Connections

1/4 in NPT

Supply Voltage (Nominal)

24 VDC

product series specifications

Supply Voltage:

22WDP-51x: 15...24 VDC, ±10%, 0.37 W; 24 VAC, ±10%, 0.9 VA

22WDP-53x: 15...24 V, ±10%, 0.5 W

Operating Temperature Range:15°F to 120°F (-10°C to 50°C)

Signal Output (Active Pressure):

22WDP-51x: DC 0-10 V

22WDP-53x: 4-20 mA

Pressure Range:

22WDP-511: 0 to 15 psi

22AWP-512: 0 to 30 psi

22WDP-514: 0 to 50 psi

22WDP-515: 0 to 100 psi

22WDP-531: 0 to 15 psi

22AWP-532: 0 to 30 psi

22WDP-534: 0 to 50 psi

22WDP-535: 0 to 100 psi

Overpressure Limit: 85 psi, Single-sided

Max. system Pressure: 300 psi

Wiring: Plug for wire 15 GA (0.5 to 1.5 mm²)

Enclosed Material: base: stainless steel 1.4305; cover: aluminum pressure

die casting

Enclosure Rating: IP65, NEMA 4

Approvals: UL 2043, UL 50

Weight: 0.55 lbs

Warranty: 5 years

product series features

Active sensor for differential pressure in liquid or dry media
Available in stainless steel or brass pipe connection adapters

more information & related documents

Series Description

Belimo's 22WDP Differential Pressure Sensor (Water) Series comes with an active sensor (0-10 V or 4-20 mA) for measuring the differential pressure in liquid or dry media. Various pressure ranges, rugged NEMA 4 / IP65 and compact stainless steel housing. Optional stainless steel or brass pipe connection adapters also available.

Kele Description

WET-WET DIFF PRESS XMTR, +/-0.50%, 0-30 PSI, 4-20

Manufacturer

Belimo
