Two grey metallic canisters joined side by side with a small black lever across them.

DDP-109 | Cleveland Controls | Pressure Components

Differential Pressure Switch, 0.02-2" WC, Adjustable, SPDT (NC), 15 A @ 277 VAC

Brand:Cleveland Controls

MPN:DDP-109

SKU:DDP-109

List Price:

$298.00

Today's Price:

$154.96

product datasheet

catalog page

Lead time of > 15 days. Chat with Kele experts now

product specifications

Direction

Uni-Directional

Measurement

Inches of Water Column

Media Compatibility

Air

Range

±5 in WC

Connection Size

1/4 in

Type

Adjustable

Connection

OD Tubing

Housing Material

Metallic

Contact Rating

1 A

Set Point Range

0.02 - 2 in

Power Required

Switch

Contact Type

SPDT

Features

Dual Set Points

product series specifications

Supply Voltage: Not required

Contact Type: Dual SPDT with Independent Set Points (SP)

Contact Rating: 15A resistive, 277 VAC, 60 Hz; 300VA pilot duty @ 115-277 VAC, 60 Hz

Setpoint (SP): Dual ADJ. from 0.05 in. to 2.0 in. W.C. (12.5 to 498 Pa) with screw

Differential Progressive: by SP from 0.02 in. to 0.1 in. WC

Reset Automatic: reset by differential

Visual Indication: None

Sensor Type: Silicone Diaphragm

Operating Pressure: Range 0.05 to 2 in. WC

Overpressure: (Burst) 13.8 in. WC (3.45kPa)

Max Operating Pressure: (Proof) 13.8 in. WC (3.45kPa)

Operating Temperature: -40 to 176°F (-40.0°C to 80°C)

Operating Humidity: 10 to 90% Non-condensing

Wetted Parts: Silicone

Media Compatibility: Inert dry air

Process Connection: 1/4 in. compression (Face down)

Wiring Terminations: 6 Terminals (dual SPDT)

Mounting Vertical bracket: 2 holes 0.187 (0.5cm)

Enclosure Rating: Zinc-plated steel, NEMA 1

Dimensions: 4.56"W x 7.25"H x 3.5"D, (11.6 x 18.4 x 8.7 cm)

Weight: 1.5 lb (0.68 kg)

Approvals: CSA, UL Recognized File MH6213

Warranty: 1 year

product series features

Dual adjustable setpoints
Independent switch operation
Actuated by a pressure or vacuum air flow
15A SPDT switches

more information & related documents

Series Description

The Cleveland Controls Model DDP-109 Dual Setpoint Differential Pressure Switch provides dual switch action for HVAC and energy management applications. Two separately operated, independently adjustable SPDT snap-acting switches are mounted on a common foot bracket. Since the switches are set independently, an adjustable 'deadband' can be established for control circuits requiring both high and low actuation points. The unit can measure differential pressures up to 2 in W.C.

Kele Description

DIFF PRESS SW, ADJUST, 0.02-2" WC

Manufacturer

Cleveland Controls
