P9S901401 | Winters Instruments | Pressure Components
1.5" 90 Series Pressure Gauge w/ Removable Lens, 0-60 psi/kpa, +/-2-1-2% Accuracy, 1/8" NPT Center Back Mount
Brand:Winters Instruments
MPN:P9S901401
SKU:PG-15-0-60-8C
List Price:
$33.55
Today's Price:
$17.45
Log in for customized pricingproduct specifications
Direction
Uni-Directional
Measurement
PSIG
Media Compatibility
Liquid,Gas
Range
±100 psi
Connection Size
1/8 in
Type
Analog
Connection
NPT
Accuracy
2%
Dial Size
1.50 in
Filling
Dry,Wet
Mount
Center Back
product series specifications
Overpressure: 125% of FS value
Operating Temperature: -40° to 150°F (-40° to 65°C)
Wetted Parts: Brass socket, phosphor bronze bourdon tube
Window Material: Acrylic
Process Connection: 1/8" NPT or 1/4" NPT, depending on model (LM = lower mount, CBM = center back mount, PM = panel mount)
Warranty: 1 year
more information & related documents
Series Description
The PG Series Pressure Gauges are durable, cost-effective, general purpose gauges for use in a wide variety of HVAC controls and building automation applications. All gauges are compatible with air, oil, and water and have a steel case, bronze bourdon tube, acrylic lens, and dual unit psi/kPa scale. The PG Series (except model PG-05) pressure gauge has a screw-on lens and recalibrator screw. A wide variety of models, options, and accessories are available, including panel-mount models, specialty gauges, and diaphragm seals. The Model 25W100 Refrigeration Gauge is ideal for installation on refrigeration manifolds for testing air conditioning units. The compound scale is designed specifically for R134A refrigerant testing.
Kele Description
DIAL GAUGE, ANALOG, +/-2.00%, 0-60 PSIG, 1.50" DIAL, 1/8" NPT, DRY, WET, CNTR BCK MOUNT
Manufacturer
Winters Instruments
PG-05 Series Economy Gauge Specifications
