Rectangular device with colored wires and metal bracket for mounting

APT-100-1DB | Dwyer Instruments | Power Supplies

AC Power Transformer, 120 VAC Input, 24 VAC Isolated Output, 96 VA, Dual Hub, W/ Circuit Breaker

Brand:Dwyer Instruments

MPN:APT-100-1DB

SKU:APT-100-1DB

List Price:

$138.00

Today's Price:

$71.76

product datasheet

product specifications

VA Rating

100 VA

Termination

Leads

Type

Closed

Over Current Protection

Circuit Breaker

Primary Voltage

120 VAC

Secondary Voltage

24 VAC

Application

Power Controller,Powering Sensors,Driving Relays,Driving Digitals I/O Circuits,Voltage Reduction,Magnetic Switches

Mount

Foot,Dual Hub

product series specifications

Input Frequency: 50/60 Hz

Output VA Rating: 20, 40, 50, 75, 96, or 150 VA

Mounting: Slotted foot mount with single, or dual 1/2” NPT hub

Electrical Connections: Models ending in -20: 20" (508 mm) 18 AWG leads; All other models: 8.5" (210 mm) 18 AWG leads

Agency Approvals: CE, cULus

product series features

Single or dual 1/2 in NPT
Universal supply voltage input
With or without integral circuit breaker

more information & related documents

Series Description

The Dwyer APT Series AC Power Transformers provide isolated step-down to 24 VAC with models offering VA ratings of 20, 40, 50, 75, 96, or 150 VA's. These cost efficient transformers are offered in single or dual 1/2 in NPT threaded hub mounts with 8-1/2 in 18 AWG wire leads, to meet the installation requirements of a variety of building automation and control panel applications in HVAC. All models are UL Class 2 listed. Kele is the leading supplier of building automation products. When you need the right product, right now, count on Kele.

Kele Description

TRANSFORMER, 100VA, 120 VAC TO 24 VAC, FOOT/DUAL HUB MOUNT, CIRCUIT BREAKER

Manufacturer

Dwyer Instruments
