Compact grey power supply with green terminal block and red LED on top.

DCP-250-D | Kele | Power Supplies

DC Power Supply, 120 VAC Input to 24 VDC Out, DIN Rail Mount

Brand:Kele

MPN:DCP-250-D

SKU:DCP-250-D

List Price:

$175.14

Today's Price:

$91.07

catalog page

product specifications

LCD

LED

Power Supply

120 VAC

Primary Voltage Input

120 VAC

DC Voltage Output Type

Fixed

DC Voltage Output Range

24 VDC

Type

DC Power Supply

DC Current Output

250M Amps

Application

Building Automation System,HVAC,BAS

Current Output

0.25 A

Mount

DIN rail

product series specifications

Supply Voltage: 110-125 VAC, 10 VA

Output Voltage: 24 VDC (regulated)

Supply Frequency: 50/60 Hz

Regulation: ±0.5V

Output Current: 250 mA

Mounting: DIN rail mount, Hub mount, Panel/surface mount

Temperature Stability: 1%

Operating Temperature: -22° to 104°F (-30° to 40°C)

Operating Humidity: 95% RH non-condensing

Dimensions: 4.0"H x 2.25"W x 1.75"D (10.16 x 5.71 x 4.45 cm)

Weight: 1.0 lb (0.5 Kg)

Approvals: UL916 File #E185225

Warranty: 1 year

product series features

Flexible mounting for hub, panel/surface, DIN rail
Compact size
Fully enclosed
Color-coded wiring
LED indication
Transformer isolated

more information & related documents

Series Description

The DCP-250 enclosed DC power supply from Kele is a unique DC power supply that provides regulated 24 volt DC power from a 120 volt AC input. It is well suited for powering transmitters, transducers, actuators, and other equipment in building automation systems, BAS, and temperature control applications. When ordering the DCP-250 specify hub mounting, surface mounting in a panel, or DIN rail mounting.

Kele Description

DC POWER SUPPLY, DIN

Manufacturer

Kele
