PS6R-J24 | IDEC | Power Supplies
SWTCHG PWR SPLY; 100 - 240 VAC; 24 VDC OUTPUT; 20A
Brand:IDEC
MPN:PS6R-J24
SKU:PS6R-J24
List Price:
$1,329.00
Today's Price:
$691.08
Log in for customized pricingproduct specifications
Output Voltage
24 VDC
Primary Voltage Input
100-240 VAC
DC Voltage Output Type
Fixed
DC Voltage Output Range
24 VDC
Type
Enclosed Power Supply
Primary Voltage
120 VAC
DC Current Output
20 Amps
Mount
DIN rail
product series specifications
Supply Voltage: 100 to 240 VAC
Output Voltage: 21.6V to 26.4V
Frequency: 50/60 Hz
Operating Temperature: 14 to 158°F (-10 to 70°C)
Operating Humidity: 20-90% RH non-condensing
Approvals: CE, UL File #E177168
Warranty: 1 year
product series features
- 93% efficiency
- DC low LED indicator and ouput contact
- Finger-safe construction prevents electric shocks
- Can be attached to a DIN rail or directly to a panel surface
more information & related documents
Series Description
The Idec PS6R Series is a high-power and space-saving switching power suppply. Well suited for applications demanding higher power, PS6R power supply is designed for any industrial or machine application where reliable DC power is required. It's 93% efficiency reduces operation costs. The terminals are captive spring-up screws. Ring or fork terminals can be used. It is only 3.4 inW (8.5cm) and is finger safe to prevent electric shocks.
Kele Description
SWTCHG PWR SPLY; 100 - 240 VAC; 24 VDC OUTPUT; 20A
Manufacturer
IDEC
Related Documents
PS6R Series Datasheet
