HSP-121BT1RU

HSP-121-BT1RUP | Kenick | Power Monitoring & Protection

120Vac In-Line Terminals

Brand:Kenick

MPN:HSP-121-BT1RUP

SKU:HSP-121BT1RU

List Price:

$383.00

Today's Price:

$199.16



Availability: 96 In Stock
Available Inventory
These numbers are estimates based on our Memphis location and subject to change without notice based on customer demand.

Need more?
Just order your desired quantity and we'll ship the available inventory immediately while we source the remaining quantity to get you all the products you need as soon as possible.

We can also reserve the available inventory and ship once we acquire the remaining quantity from the supplier. Just choose "Ship Complete" at checkout.

product datasheet
catalog page

product specifications

Mounting

Foot

Type

120V

Number of Circuits

1

Operating Voltage

120 V

product series specifications

    Supply Voltage:
  • 120 VAC, 60 Hz
    Supply Current:
  • 15A
    LED Indication:
  • Extinguishes on overload or internal protection failure
    Clamping Level Maximum 325V L-N, 350V L-G:
    Clamping Category:
  • 330V L-N, 400V L-G ANSI/IEEE C62.41 1991-CAT.C1/B3
    Surge Current:
  • Maximum 10,000A
    Fusing:
  • 15A slowblow (GF-15S) Blown fuse will disconnect load from power source.
    Response Time:
  • <5 ns
    Connections:
  • Terminals
    Operating Temperature:
  • -3° to 186‚Ñâ (-20° to 85‚ÑÉ)
    Dimensions:
  • 2.95"H x 5.25"W x 2.0"D (7.5 x 13.3 x 5.1 cm)
    Weight:
  • 0.83 lb (0.38 Kg)
    Warranty :
  • 5 year

product series features

  • 120V - 15Amp hardwired
  • Automatic recovery
  • Fast response acting
  • Power line tracking
  • 3 stage hybrid design

more information & related documents

Series Description

The HSP-121BT1RUP is an advanced, three-stage, hybrid solid-state power line protector. It is an in-line style surge protector designed for mounting in an enclosure or control panel to protect sensitive electronic controls from noise, surges, and spikes that are present on the power lines.

Kele Description

120VAC IN-LINE TERMINALS

Manufacturer

Kenick

Related Documents

PDF - HSP121-BT-1RU CutsheetHSP121-BT-1RU Cutsheet
