Rectangular black surge protector with yellow lightning graphic on the front

DRS-036 | Kenick | Power Monitoring & Protection

Din Rail Data Line Surge Protector, 36V

Brand:Kenick

MPN:DRS-036

SKU:DRS-036

List Price:

$360.00

Today's Price:

$187.20

product datasheet

Lead time of 8 days. Chat with Kele experts now

product specifications

Operating Voltage

36 V

Number of Circuits

Mount

DIN rail

product series specifications

Voltage Clamp: (±10%) 8, 15, 30, or 36V

Response Time: <1 ns

Peak Surge Current: <10 kA (8 x 20 Œºs)

Life Expectancy: >100 occurrences @ 2000A, 8 x 20 Œºs

Series Resistance: 5Ω nominal

Operating Temperature: -40° to 185°F (-40° to 85°C)

Dimensions: 2.95" H x 0.8" W x 2.35" D (7.5 x 2.0 x 6.0 cm)

Capacitance: 1500 pF; PC642 w/ LC option: 50 pF

Operational Current: Maximum 150 mA @ clamp voltage

Protector Primary: Three-element gas tube (GDT), Secondary Rugged solid-state avalanche diode SAD), Third Positive temp coefficient device (PTC)

Approvals: UL497B, File #E175287

Weight: 0.06 lb (0.03 kg)

Warranty: 1 year

product series features

Low-voltage data surge
Three-stage hybrid design
Sneak/fault current protection (PTCs)
Easy to install
Fits standard 35mm DIN rails
Low profile size

more information & related documents

Series Description

The DRS (DC) Series is a DIN rail mountable, single-pair surge suppression module implementing three-stage hybrid technology. This module addresses over-voltage transients with gas tubes and silicon avalanche components. In addition, sneak currents are mitigated with automatic resetting fuses (PTCs). The PTCs increase resistance several orders of magnitude when over-currents exceed safe levels. A normal sate resumes when over-currents are removed. The ability to self-restore in this manner significantly increases suppressor performance and survivability. The DRS (DC) Series mounts onto a standard 35 mm industrial DIN rail. There are three in.Field Side in. and three in.Electronic Side in. screw terminals. One is reserved for a shield. Three electrically tied ground terminals are provided for grounding the DRS Series unit to Building-Approved Ground.

Kele Description

DIN RAIL DATA LINE SURGE PROTECTOR, 36V

Manufacturer

Kenick
