DRS-008

DRS-008 | Kenick | Power Monitoring & Protection

Din Rail Data Line Surge Protector, 8V

Brand:Kenick

MPN:DRS-008

SKU:DRS-008

List Price:

$227.00

Today's Price:

$118.04



Availability: 19 In Stock
Available Inventory
These numbers are estimates based on our Memphis location and subject to change without notice based on customer demand.

Need more?
Just order your desired quantity and we'll ship the available inventory immediately while we source the remaining quantity to get you all the products you need as soon as possible.

We can also reserve the available inventory and ship once we acquire the remaining quantity from the supplier. Just choose "Ship Complete" at checkout.

product datasheet

product specifications

Mounting

DIN Rail

Type

8V

Number of Circuits

1

Operating Voltage

8 V

product series specifications

    Voltage Clamp :
  • (±10%) 8, 15, 30, or 36V
    Response Time:
  • <1 ns
    Peak Surge Current:
  • <10 kA (8 x 20 Œºs)
    Life Expectancy:
  • >100 occurrences @ 2000A, 8 x 20 Œºs
    Series Resistance :
  • 5‚Ѷ nominal
    Operating Temperature:
  • -40° to 185‚Ñâ (-40° to 85‚ÑÉ)
    Dimensions :
  • 2.95"H x 0.8"W x 2.35"D
    :
  • (7.5 x 2.0 x 6.0 cm)
    Capacitance:
  • 1500 pF; PC642 w/ LC option: 50 pF
    Operational Current :
  • Maximum 150 mA @ clamp voltage
    Protector Primary :
  • Three-element gas tube (GDT)
    :
  • Secondary Rugged solid-state avalanche diode (SAD)
    :
  • Third Positive temp coefficient device (PTC)
    Approvals:
  • UL497B, File #E175287
    Weight :
  • 0.06 lb (0.03 kg)
    Warranty :
  • 1 year

product series features

  • Low-voltage data surge
  • Three-stage hybrid design
  • Sneak/fault current protection (PTCs)
  • Easy to install
  • Fits standard 35mm DIN rails
  • Low profile size

more information & related documents

Series Description

The DRS (DC) Series is a DIN rail mountable, single-pair surge suppression module implementing three-stage hybrid technology. This module addresses over-voltage transients with gas tubes and silicon avalanche components. In addition, sneak currents are mitigated with automatic resetting fuses (PTCs). The PTCs increase resistance several orders of magnitude when over-currents exceed safe levels. A normal sate resumes when over-currents are removed. The ability to self-restore in this manner significantly increases suppressor performance and survivability. The DRS (DC) Series mounts onto a standard 35 mm industrial DIN rail. There are three in.Field Side in. and three in.Electronic Side in. screw terminals. One is reserved for a shield. Three electrically tied ground terminals are provided for grounding the DRS Series unit to Building-Approved Ground.

Kele Description

DIN RAIL DATA LINE SURGE PROTECTOR, 8V

Manufacturer

Kenick

Related Documents

PDF - DRS CutsheetDRS Cutsheet
