DTK-DR240P1

DTK-DR240P1 | Ditek | Power Monitoring & Protection

DIN RAIL SPD 240VAC SINGLE PHASE, 1 POLE

Manufacturer:Ditek

MPN:DTK-DR240P1

SKU:DTK-DR240P1

list price:

170.32

85.16



(login for better pricing)
USD

availability:Usually Ships in Less Than 15 Business Days

add to cart

arrow

product family specifications

Surge Current Rating

 75,000 Amps

SCCR

 200,000A RMS

Frequency

 50-60Hz

Connection Method

 Hardwired: #14-4AWG Solid/Stranded Cu

 Dry Contact: #30-16AWG

Housing

 IP20, UL94 V0

Mounting

 DIN-Rail - 35mm

Surge Protection Status

 Green - Normal, Red - Replace

Remote Monitoring

 Form C Dry Contact, 250VAC/1A Max, 125VAC/3A Max

Operating Temperature

  -40 degree F - 185 degree F (-40 degree C - 85 degree C

Humidity

 5 - 95% Relative

Dimensions

  4.19" L x 0.69" W x 2.81" H (1 pole) (106mm x 18mm x 71mm)



Approvals

 UL1449 4th Edition Recognized/CE

SPD Type

  Type 1CA, Type 2CA (Canada)

Standard Compliance

 ANSI/UL1449 4th Edition

 ANSI/IEEE C62.41.1, C62.41.2, C62.45

 RoHS Compliant

Warranty

  5 year limited

product family features

  • Compact, modular design for easy integration within machine control panels
  • Quick replacement of protection module when needed
  • DIN-Rail mounting configuration
  • Remote end of life indicator for surge protection status: NO/NC Form C Dry Contact
  • Visual end of life indicator for surge protection status: RED=End of life

more information & related documents

Family Description

Ditek's DIN-Rail DTK-DR Series surge protectors are designed to protect against the harmful effects of transient surges caused by direct or indirect lighting, power company grid switching and inductive load switching. These high-performance SPD's provide point-of-use surge protection for critical operations within commercial and industrial environments.

Kele Description

DIN RAIL SPD 240VAC SINGLE PHASE, 1 POLE

Manufacturer

Ditek
