WNC-3D-240-MB | Continental Control Systems, LLC | Power Monitoring & Protection
WATTNODE POWER MTR 3 PHASE 3 WIRE 120V/208V MODBUS
Brand:Continental Control Systems, LLC
MPN:WNC-3D-240-MB
SKU:WNC-3D-240-MB
product specifications
CT Inputs
3
Monitored Voltage
208 VAC
Monitored Current
6,000 A
Communication Protocol
MODBUS
product series specifications
Supply Voltage: 120 to 600VAC
CT Input: 0.333V nominal, 3V maximum
Communication Protocol: BACnet MS/TP (RS-485)
Modbus RTU: LonWorks Network Variables (SNVTs):
Signal LEDs: Diagnostic LEDs Provide per-phase indication of power (green flashing) and negative power (red flashing) on BACnet, Modbus and Pulse models only
Operating Temperature: -22° to 131°F (-30 to 55°C)
Operating Humidity: 5 to 90% RH up to 104°F (40°C)
Dimensions: 5.63" x 3.34" x 1.5" (14.3 x 8.5 x 3.8 cm):
Weight: 0.7 lb (0.31 Kg)
Approvals: CE, UL File #312220 FCC Class B, EN 55022 Class B, RoHs:
Warranty: 5 Years
product series features
- BACnet, Modbus, Lonworks or Pulse
- 1 to 3 Phase 120VAC to 600VAC
- 0.5% nominal accuracy (see manual for details)
- Euroblock style pluggable screw terminal blocks
- Line powered
- Uses safe current transformers; 0.333V output
- Bidirectional
more information & related documents
Series Description
The Continental Control Systems WNC Series of AC Power measurement meters are available in pulse output or will support several communication protocol outputs. True power, kWh reactive power, VARs, power factor, and individual phase measurements. Diagnostic LEDs provide a per-phase indication of power (green flashing) and negative power (red flashing) to help troubleshoot connection problems such as swapped CT's or excessive live voltage. The meters use the safe Ct's producing 0.333 VAC at rated current. They have a small form factor for easy installation inside most electrical panels with pluggable screw terminals for easy wiring. Power Related Measurements - 50+ for BACnet and Modbus; 27+ for LonWorks.
Kele Description
WATTNODE POWER MTR 3 PHASE 3 WIRE 120V/208V MODBUS
Manufacturer
Continental Control Systems, LLC
WNC Series Modbus Install Guide
