CT-SRL-200-U | Dent Instruments | Power Monitoring & Protection
200A LARGE REVENUE-GRADE HINGE-SNAP 1.25IN
Brand:Dent Instruments
MPN:CT-SRL-200-U
SKU:CT-SRL-200-U
List Price:
$253.00
Today's Price:
$131.56
Log in for customized pricingproduct specifications
Type
Split Core
Output
0.333 V
Rated Current
200 A
Window Size
1.25 in
product series specifications
Current Range:
100A Model 1.0-200A AC
200A Model 2.0-400A AC
400A Model 4.0-500A AC
Frequency: 40 to 400 Hz
Working Voltage: 600 VAC, Category III
Lead Wires: 8ft (2.4M) black and white twisted pair 18 AWG MTW UL1015, 600V, 105°C double insulated
Window Size: 1.25" (31.75mm)
Materials Of Construction: 120°C UL Recognized Plastic
Weight: 0.75 lbs
Approvals: Conforms to: UL Listed to UL 2808, Certified to: CSA STD C22.2 No. 61010-1
Warranty: 1 year
product series features
- Superior Performance
- Robust design
- Unique shrouded snap, lock and tilt top
more information & related documents
Series Description
The Dent Instruments CT-SRL Series are hinged split-core current transformers are designed for Revenue Grade applicatons that require maximum accuracy and precision. The superior performance, robust design, and unique shrouded snap, lock & tlt top of the SRS Series CTs make them ideal for feld installaton in high accuracy current measurement applicatons such as energy and demand metering, tenant submetering and load surveys. Revenue Grade performance of these CTs meets or exceeds the accuracy specifcatons of IEC 61869-2 Class 0.2; IEC 60044-1 Class 0.3; and IEEE C57.13 Class 0.3. The SRL Series CTs are UL2808 and CSA C22.2 No. 61010-1 listed as stand-alone products, CE marked, RoHS compliant, and are 600V CAT III rated devices. They are available for current inputs up to 400 Amps with 8 foot long, 18 AWG MTW UL1015 twisted pair leads.
Kele Description
200A LARGE REVENUE-GRADE HINGE-SNAP 1.25IN
Manufacturer
Dent Instruments
Related Documents
REVENUE GRADE LARGE INSTRUCTIONS
