CT-SCM-0100-U | Dent Instruments | Power Monitoring & Protection

100A MEDIUM SPLIT-CORE 1.25” (32MM) OPENING

Brand:Dent Instruments

MPN:CT-SCM-0100-U

SKU:CT-SCM-0100-U

List Price:

$-.--

Today's Price:

$-.--

product datasheet

installation instructions

catalog page

product specifications

Type

Split Core

Rated Current

100 A

Window Size

1.25 in

Output Signal

.333 V

product series specifications

Current Range:

100A Model 5 - 130A AC

200A Model 4 - 260A AC

400A Model 8-520A AC

600A Model 12-780A A

Frequency: 50-400 Hz

Working Voltage: 600 VAC, Category III

Lead Wires: 2.7 M (8'), twisted pair, 20 AWG

Window Size: 1.25" (3.20cm)

Materials Of Construction: Epoxy encapsulated housing

Weight: 0.80 lbs

Approvals:

UL STD 61010-1, CAN/CSA STD C22.2 No. 61010-1

Warranty: 1 year

product series features

Safely and easily installed
No interruption of service

more information & related documents

Series Description

The Dent Instruments CT-SCM Series are split-core current transformers that provide linear output voltage that is directly proportonal to the input current. These transformers are safely and easily installed over existng electrical power lines without disconnectng the lines or interruptng service. Dent Instrument's energy monitoring components are used for a variety of applicatons including building automaton, tenant submetering, performance verifcaton, energy management, and new technology assessment.

Kele Description

100A MEDIUM SPLIT-CORE 1.25" (32MM) OPENING

Manufacturer

Dent Instruments
