Beige square current transformer with a rectangular window in the middle, labelled Dent Instruments 600 AMP, and a long black and white coiled wire extending from the bottom.

CT-SCL-1000-U | Dent Instruments | Power Monitoring & Protection

1000A LARGE SPLIT-CORE CT, 2IN WINDOW, 3M LEADS

Brand:Dent Instruments

MPN:CT-SCL-1000-U

SKU:CT-SCL-1000-U

List Price:

$202.00

Today's Price:

$105.04

catalog page

Lead time of 10 days. Chat with Kele experts now

product specifications

Type

Split Core

Output

0.333 V

Rated Current

1,000 A

Window Size

2 in

product series specifications

Current Range:

600A Model 30 - 780A AC

1000A Model 20 - 1300A AC

Frequency: 50-400 Hz

Working Voltage: 600 VAC, Category III

Lead Wires: 2.7 M (8'), twisted pair, 20 AWG

Window Size: 2.0" (5.10cm)

Materials Of Construction: Epoxy encapsulated housing

Weight: 1.75 lbs

Approvals: UL STD 61010-1, CAN/CSA STD C22.2 No. 61010-1

Warranty: 1 year

product series features

Safely and easily installed
No interruption of service

more information & related documents

Series Description

The Dent Instruments CT-SCL Series are split-core current transformers that provide linear output voltage that is directly proportonal to the input current. These transformers are safely and easily installed over existng electrical power lines without disconnectng the lines or interruptng service. Dent Instrument's energy monitoring components are used for a variety of applicatons including building automaton, tenant submetering, performance verifcaton, energy management, and new technology assessment.

Kele Description

1000A LARGE SPLIT-CORE CT, 2IN WINDOW, 3M LEADS

Manufacturer

Dent Instruments
