Black pneumatic actuator with exposed spring

MP953E1319/U | Honeywell | Pneumatics & Fittings

Pneumatic Valve Actuator 5" Dia,5 Psi W/Position,3/4" Str,N/Up

Brand:Honeywell

MPN:MP953E1319/U

SKU:MP953E1319

List Price:

$2,841.53

Today's Price:

$1,477.60

product datasheet

installation instructions

catalog page

Lead time of > 15 days. Chat with Kele experts now

product specifications

Type

Direct Acting

Pressure Range

5 PSIG

Stroke

3/4 in

product series specifications

Connections:

Barb for 1/4" or 1/8" OD poly tubing; 1/8" NPT for brass fitting

Diaphragm:

Operating Temperature:

-20° to 150°F (-29° to 66°C)

Media Temperature Range:

Maximum fluid temperature 338°F (170°C), 100 psig (103 kPa) steam

Maximum Pressure:

25 psig (172 kPa)

Warranty:1 year

product series features

Rolling diaphragm for long life and low hysteresis
Easily attached to valve
May be installed after piping valve
Slide lock feature permits simple engagement to stem
Direct or reverse-action control
Models available with pilot positioner

more information & related documents

Series Description

The Honeywell MP953 Series pneumatic globe valve actuators operate Honeywell V5011, V5013 (threaded) and VGF (flanged) Series valves to provide proportional control of steam or hot water or cold water in HVAC systems.

Kele Description

PNEU VLV ACT 5" DIA,5 PSI W/POS,3/4" STR,N/UP

Manufacturer

Honeywell
