Line drawing of a pneumatic reversing relay.

243-0024 | Siemens Industry | Pneumatics & Fittings

RL243 REVERSING RELAY

Brand:Siemens Industry

MPN:243-0024

SKU:243-0024

List Price:

$680.00

Today's Price:

$353.60

product datasheet

installation instructions

catalog page

Lead time of 4 days. Chat with Kele experts now

product specifications

Type

Relay

product series specifications

Operating Range: 0 to 30 psi (0 to 207 kPa)

Adjustment Using 5/64" Hex Wrench:

Range Adjustment: 10 to 30 psi (69 to 207 kPa)

Factory Setting: 15 psi (103 kPa)

Maximum Air Pressure: 30 psig (207 kPa)

Ambient Temperature Range: 140°F (60°C)

Air Connections: Barbed nipple for 1/4" OD polyethylene tubing

Mounting: Mounting bracket provided

Air Capacity: 230 scfm (63 ml/sec)

Air Consumption for Compressor Sizing: 29 scfm (8 ml/sec)

Housing: Glass-filled nylon

Weight: 0.27 lb (0.13 kg)

product series features

Lightweight and small in size
Can be mounted in any position (mounting bracket and screws included)
Field adjustable spring range
Can be used as a signal inverting relay
Force-balance operation minimizes air consumption
Internal relief provides fail-safe operation
Amplifies air volume to minimize system lag

more information & related documents

Series Description

The Siemens/Powers 243-0024 Series Reverse Acting Relay provides a proportional output signal that varies inversely with the input signal. A spring adjustment is provided to allow setting a desired reverse acting schedule required by a particular application.

Kele Description

PNEU/REVERSING RELAY/W/BRKT

Manufacturer

Siemens Industry
