195-130 | Siemens Industry | Pneumatics & Fittings

Control Action: Direct action (DA), Reverse action (RA)

195-0011 - Input 1: Direct action (DA)

195-0011 - Input 2: Reverse action (RA)

195-0003 - Input 1: Direct action (DA)

195-0003 - Input 2: Reverse action (RA)

195-0003 - Input 3: Direct reset relative to Input 2, Reverse reset relative to Input 1

Pneumatic Inputs: 3 to 15 psi (21 to 103 kPa)

Control Output: 0 psi (0 kPa) to supply pressure

Ambient Temperature Range: 40 to 120°F (4 to 49°C)

Supply Pressure: Operating: 22 psi (152 kPa), Maximum Safe: 30 psi (207 kPa)

Percent Proportional Band Adjustment Range: 2 to 20% for a 5 psi (34 kPa) control pressure change

Percent Authority Adjustment Range: 20 to 200%

Air Consumption: 60 scfm (17 ml/sec)

Mounting: Surface

Air Connections: Barb fittings for 1/4" (6 mm) OD plastic tubing

195-0011: Two plug-in connectors are provided: one for the direct acting and the reverse acting transmitter inputs and one for supply and control lines.

1/8" NPT connection provided for control pressure gauge (gauge not included).

195-0003: Two plug-in connectors are provided: one for the three transmitter inputs and one for supply and control lines.

1/8" NPT connection provided for control pressure gauge.

Case Material: Lexan, 20% glass filled

Dimensions: 5 11/16"H x 6 3/4"W x 3 1/2"D (14.5 x 17.2 x 8.9 cm)

Weight: 3.1 lb (1.4 Kg)
