193-211 | Siemens Industry | Pneumatics & Fittings

Control Action: Direct or reverse acting

Connections: Barbs for 5/32″ OD poly tubing

Number of Pipes: 1 or 2 depending on model selected

Sensor Element: Bi-metal

Sensitivity Adjustment: 1 to 4 psi/°F (12 to 50 kPa/°C)

Setpoint Temperature Ranges: 45 to 85°F (7 to 30°C)

Temperature Response: 0.1°F to (0.06°C)

Dial Graduations: 2°F (1°C)

Factory Settings:

Calibration: 72°F (22°C) 7.5 psi (52 kPa)

Sensitivity: 2.5 psi/°F (31 kPa/°C)

Limit Stop Adjustment: 45°F and 85°F (7°C and 30°C)

Maximum Operating Pressure: 30 psi (207 kPa)

Normal Air Pressure: 18 to 25 psi (124 to 172 kPa)

Nominal Air Consumption:

192 Series:25 scim (6.8 ml/sec)

Day/Night and Heat/Cool, two pipe:

192 Series:

Single Temperature:

One Pipe: 25 scim (6.8 ml/sec)

Two Pipe: 20 scim (5.5 ml/sec)

193 Series: 40 scim ( 11 ml/sec)

Deadband: 193 Series Only

Output Pressure Adjustment: 1 to 15 psi (7 to 103 kPa)

Range: 0 to 40°F (0 to 20°C)

Storage Temperature: -10 to 140°F (-23 to 60°C)

Ambient Operating Temperature: 40 to 140°F (4 to 60°C)

Standard Cover: Cycolac, desert beige

Dimensions: 3 11/32″H x 2 5/32″W x 1 19/32″D (8.5 x 5.5 x 4.0 cm)

Shipping Weight: 0.7 lbs. (0.3 kg)

Warranty: 1 year
