* product series image displayed

LVSM4PLIV | Hubbell Electrical Products | Lighting Controls

LVSWITCH, MOM, 4 BUTTON, W/PILOT LED, IVORY

Brand:Hubbell Electrical Products

MPN:LVSM4PLIV

SKU:LVSM4PLIV

List Price:

$332.00

Today's Price:

$172.64

catalog page

Lead time of > 15 days. Chat with Kele experts now

product specifications

Color

Ivory

Type

4 Switch

Supply Voltage (Nominal)

24 VDC

Mount

Wall

product series specifications

Supply Voltage: None Required

Switch Rating: SPST N.O., 30 VDC Max @100 mA per switch

Switch Buttons: 1-4 Momentary push buttons

Status indication: Optional 1-4 Green LED, 18-30VDC (Externally powered)

Operating Temperature: 32° to 122°F (0° to 50°C)

Operating Humidity: 10% to 90% non-condensing

Wiring Terminations: Switch, 6" 24 AWG Pigtails

Wire Interconnection: Opt. LED, independent 6" 24 AWG Pigtails

Mounting: Typical vertical switch box, w/wo opt. plate (P)

Color: White (WH) or Ivory (IV)

Enclosure Rating: NEMA 1

Dimensions: STD. Decora®, +P Option with Opt. Plate = 2.78"W x 4.5"H

Weight: 0.19 lb (0.09 Kg)

Approvals: Title 24 compliant, RoHS

Warranty: 5 year

product series features

Momentary operation
Latching versions available
1-4 buttons with or without LED
Mounts to standard single-gang box

more information & related documents

Series Description

The Hubbell LV Series low voltage wall switches are designed for virtually any area. Switches are momentary when pressed and feature single or multiple button configurations with and without a pilot LED.

Kele Description

LVSWITCH, MOM, 4 BUTTON, W/PILOT LED, IVORY

Manufacturer

Hubbell Electrical Products
