White plastic wall plate with sharply angled top and a small rectangular cut-out near the bottom.

HW30K-T21-XMH | Kele | Humidity

Room Humidity Transmitter, 3% Beige, 4-20 mA output, 2.252K Temperature Sensor, with Override

Brand:Kele

MPN:HW30K-T21-XMH

SKU:HW30K-T21-XMH

List Price:

$220.00

Today's Price:

$114.40

product datasheet

Call 877.826.9045 for availability

product specifications

Accuracy

Housing Material

Poly

Sensor Element

2.2K Thermistor

Output

4 - 20 mA

Power Requirements

24 VAC/VDC

Accessory

DCPA-1.2,DCP-1.5-W,T81U-XR,T85U-XR,UR

Application

Humidification,Dehumidification,Monitoring Indoor Space Humidity,Clean Rooms,Hospitals,Process Control,Laboratories,Museums,Schools,Office Buildings,Data Centers,ESD (Anti-Static) Control

Mount

Room

product series specifications

Accuracy: 3% RH @ 73°F (23°C) from 5% to 90%; (0-5% and 90%-100%) add 4%

Stability: typically <0.5% drift per year

Thermal Effect: 0.07% per °F

Supply Voltage: 9.5-28 VDC, loop powered

Signal Output: 4-20 mA @ 725Ω, optional thermistor, RTD

Measurement Range:

RH: 0-100%

Temperature: -20° to 140°F (-29° to 60°C) (see ordering information)

Sensor Protection: HDPE FGX filter (duct and OSA)

Operating Temperature: -20° to 158°F (-29° to 70°C)

Operating Humidity: 0-100% RH non-condensing

Enclosure Rating:

Room: NEMA 1

Duct/OSA: NEMA 4, weather resistant cast aluminum

Wiring Terminations: Terminal block (22 to 16 AWG)

Weight:

Wall: 0.3 lb (0.09 Kg)

Duct: 1.14 lb (0.52 Kg)

OSA: 1.2 lb (0.54 Kg)

Approvals: RoHs

Warranty: 1 year

product series features

3% accuracy (5% to 90%)
Two wire, 4-20mA RH output
Optional temperature thermistor
Optional temperature RTD

more information & related documents

Series Description

The Kele Series H_30K humidity transmitters have been specifically designed to measure humidity in HVAC applications and building automation systems, BAS. These humidity sensors measure relative humidity from 5 to 95% RH with ±3% accuracy and transmit via a two wire, 4-20mA linear output. All transmitters come equipped with an optional passive RTD or thermistor.

Kele Description

3% WALL MOUNT RH XMTR W/SNR 2252 OHM THMS PSH BTTN

Manufacturer

Kele
