White wall-mounted sensor with a tiny digital display near the top and two grey arrow buttons below.

HTRC2LVS | Greystone Energy Systems | Humidity

Room Humidity and Temperature Transmitter, Wall Mount, 2%, Viewable LCD Display, 0-5 VDC or 0-10 VDC (Menu Selectable), Override Switch (includes Occupied Input)

Brand:Greystone Energy Systems

MPN:HTRC2LVS

SKU:HTRC2LVS

List Price:

$691.00

Today's Price:

$359.32

product datasheet

installation instructions

Lead time of 12 days. Chat with Kele experts now

product specifications

Accuracy

Housing Material

Poly

Temperature Range

0 to 35 °C,32 to 95 °F,0 to 50 °C,32 to 122 °F

Output

0 - 5 VDC

Display

LCD

Override

Enclosure Rating

IP30,NEMA 1

Power Requirements

24 VAC/VDC

Accessory

DCPA-1.2,DCP-1.5-W,UR

Application

Humidification,Dehumidification,Monitoring Indoor Space Humidity,Clean Rooms,Hospitals,Process Control,Laboratories,Museums,Schools,Office Buildings,Data Centers,ESD (Anti-Static) Control

Mount

Room

more information & related documents

Series Description

The Greystone Energy Systems HRC Series Executive Wall Humidity transmitters are specifically designed for use in HVAC/BAS applications. These instruments measure relative humidity from 0% to 100%. The Greystone Energy Systems HTRC Executive Wall Series Humidity transmitters has dual analog outputs for humidity and temperature.

Kele Description

2% HUM/TEMP WALL 0-5/10 VDC 32-95F LCD OVERRIDE

Manufacturer

Greystone Energy Systems
