White thermostat with blue-lit display reading 66 and three grey buttons beneath the screen

TCY-BH-U-W24 | Vector Controls Ltd | Humidity

5% Wall Mount Humidistat W/Display And Fan Control

Brand:Vector Controls Ltd

MPN:TCY-BH-U-W24

SKU:TCY-BH-U-W24

List Price:

$436.46

Today's Price:

$226.96

product datasheet

installation instructions

catalog page

Lead time of 12 days. Chat with Kele experts now

product specifications

Type

Wall

Accuracy

Housing Material

Poly

Sensor Element

10K Thermistor

Output

4 - 20 mA

Display

LCD

Power Requirements

24 VAC/VDC

Accessory

AES-HT-A5,S-TN10,SD-TN10,DCPA-1.2,DCP-1.5-W,UR

Feature

Fan Control

Application

Humidification,Dehumidification,Monitoring Indoor Space Humidity,Clean Rooms,Hospitals,Process Control,Laboratories,Museums,Schools,Office Buildings,Data Centers,ESD (Anti-Static) Control

Mount

Room

product series specifications

Accuracy: ±5% RH (10-90%)

Supply Voltage: 24 VAC ±10%, 50/60 Hz @ 1.5 VA; 24 VDC ±10% @ 62.5 mA

Analog Input: 10k Type II (Type 24) Thermistor

Relay Output: 2 NO SPST Relays, 1.2 Amps @ 24 VAC

Operating Temperature: 32° to 122°F (0° to 50°C)

Operating Humidity: 0% to 95% non-condensing

Enclosure Rating: NEMA 1, ABS plastic (UL94 class V-0)

Wiring Terminations: Terminal block (12 to 24 AWG)

Dimensions: 4.4"H x 2.9"W x 1.8"D (11.2 x 7.3 x 4.7 cm)

Weight: 0.58 lb (0.26 Kg)

Approvals: CE

Warranty: 2 years

product series features

Humidification and dehumidification control
External temperature input for set point setback
Programmable user interface
Optional time clock, 24 hour, 7 day
2 relay outputs
Easy to read display
Replaceable sensor

more information & related documents

Series Description

The Vector TCY-BH-U Series wall mount humidistat is a stand-alone programmable electronic humidistat designed for controlling humidification and dehumidification equipment in HVAC and energy management systems. The TCY-BH-U Series features one internal humidity sensor, one external temperature sensor input and two relay outputs. Humidity reset is possible using the ST-024 outdoor air temperature sensor for cold weather applications to prevent condensation. The TCY-BH-U-D Series comes with all of the features of the base model plus a time clock feature for advanced programming with 48 hour backup.

Kele Description

5% WALL MOUNT HUMIDIFYING HUMIDISTAT W/DISPLAY AND FAN CONTROL

Manufacturer

Vector Controls Ltd
