* product series image displayed

105STB-N5 | Edwards Signaling | Hazardous Locations

This item has been discontinued and is no longer available for purchase.

Need assistance? Call 877.826.9045 or for replacement options.

product specifications

Type

Strobe

Contact Type

Blue

Input

120 VAC

Mount

Multi

Heavy-duty, high-decibel vibrating horn
Corrosion-resistant epoxy finish
NEMA 4X
Wall-mounting with side brackets
Power connection wires embedded in sealing compound
Tapped for 3/4 in. conduit
97 dB at 10 feet
120 VAC (878EX-N5), 24 VDC @ 160 mA (879EX-G1)
UL listed for Class 1, Divisions 1 and 2, Groups B, C, D; Class II, Divisions 1 and 2, Groups E, F; Class III locations
UL File #E14660<ul><li /></ul>High-impact glass dome
65 flashes per minute
800,000 peak candlepower
3000-hour lamp rating
NEMA 3R and 4X rated
UL listed 1638, 1203, Marine 1598A; CUL listed C22.2 No. 205; Class I, Division 1, Groups C, D; Class I, Division 2, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; Class II, Division 2, Group F, G; Class III, Division 1, Groups E, F, G; Class III, Division 2, Group G
UL File #E212211
12.8 in.H x 7.3 in.W x 6.8 in.D (32.5 x 18.5 x 17.3 cm)

Series Description

The 878EX, 879EX, 116EXMST Series Edwards Signaling horns and strobes offer a selection that should meet any hazardous location alarming need.

Kele Description

XP DIV 2 STROBE BLUE 120V

Manufacturer

Edwards Signaling
