PC1412SPK | Stahlin Enclosures | Enclosures

ALUMINUM SWING PANEL KIT, POLYSTAR, 14X12

Brand:Stahlin Enclosures

MPN:PC1412SPK

SKU:PC1412SPK

List Price:

$202.00

Today's Price:

$105.04

product datasheet

Lead time of 13 days. Chat with Kele experts now

product specifications

Type

Solid Panel

Material

Aluminum

Enclosure Width

12 in

Enclosure Height

14 in

Mount

Hinged

product series specifications

Material: polycarbonate with UV inhibitors

Gasket Material: neoprene rope style, poured polyurethane seamless gasket on select sizes

Recessed Screws: no protruding surfaces

Stainless Steel Hardware: 300 Series Stainless Steel

Mounting Bosses: panel mounting capability for fixed rear panel

Metal Inserts: all threaded brass inserts accepting 10-32 screws

Side Mount Solutions: variable height, any side mount capability

Hinge and Latch Material: polycarbonate with UV inhibitors

Color: available standard in RAL 7541C

NEMA 250, cULus Listed UL50,UL50e,UL508A: UL Listed File: E319779, Type 1, 3R, 4, 4X, 6P, 12

IEC60529: UL Listed File: E362920; IP66, IP68

Temperature Range: (-40°F to +248°F) (-40°C to +120°C)

Flammability Rating: UL94-5V0

Self Extinguishing: non-halogenated, non-flame propagating

Chemical Resistance: full chemical resistance charts listed in appendix

Outdoor UV Exposure: (fl) Rated

product series features

Utilized for outdoor and indoor applications
Polycarbonate material with UV inhibitors
Designed to perform in cold-weather applications

more information & related documents

Series Description

The Stahlin PolyStar® enclosures are intended to be utilized for outdoor and indoor applications, manufactured with polycarbonate designed to perform in cold-weather applications. In general, the product performance will not be adversely affected until temperatures below -40°F are realized.

Kele Description

ALUMINUM SWING PANEL KIT, POLYSTAR, 14X12

Manufacturer

Stahlin Enclosures
