Specialized solenoid valve with a brass three-way body, black enclosure and a red-capped manual override button, certified for hazardous environments.

JPIS8223B303 DC 24/DC | ASCO | Control Valves

ASCO JPIS8223B303 2-WAY N/C 1/2" INTRINSICALLY SAFE SOLENOID VALVE, 24 VDC

Brand:ASCO

MPN:JPIS8223B303 DC 24/DC

SKU:JPIS8223B303 DC 24/DC

List Price:

$3,358.00

Today's Price:

$1,524.00

Lead time of > 15 days. Chat with Kele experts now

product specifications

Max Media Temperature

149 °F

Media Compatibility

Air-Inert Gas

Power Supply

DC Line Power

Type

Two Way

Valve Operation

Normally Closed

Orifice Size

3/8 in

Is FM

true

Solenoid Coil

298008-002

Solenoid Kit

325211

Body Material

Brass

3.2 CV

Pipe Size

1/2 in

Wetted Materials

Brass, PUR/NBR

Pressure Range

25 - 130 PSI

Supply Voltage (Nominal)

24 VDC

Function

HIgh Pressure

Seal Material

PUR/NBR

product series specifications

Valve Function: High Pressure

Solenoid Valve Type: Two Way

Operation: Normally Closed

Body Material:Brass

Pipe Size: 1/4 Inch, 3/8 Inch, 1/2 Inch, 3/4 Inch

Valve Media: Air-Inert Gas, Water-Clean Liquids, Light Oil

product series features

Rugged piston construction built to withstand pressure ratings to 1500 PSI
Available in 1/4" to 3/4" pipe sizes
Angle-body design with 90° inlet and outlet post design for high flow rates
Mountable in any position
Brass body, stainless steel core tube and spring
Handles air, water, and oil media

more information & related documents

Series Description

Two-way pilot-operated high pressure solenoid valves. Sizes 1/4" to 3/4". Normally closed operation. High pressure valves with brass body.

Kele Description

ASCO JPIS8223B303 2-WAY N/C 1/2" INTRINSICALLY SAFE SOLENOID VALVE, 24 VDC

Manufacturer

ASCO
