V5011B1013 | Honeywell | Control Valves
4IN 160CV 35-275F VAL CAST IRON
Manufacturer:Honeywell
MPN:V5011B1013
SKU:V5011B1013
List Price:
$14,267.51
Today's Price:
$7,419.11
product family specifications
Size
1/2" to 2" FNPT
Cv Range
0.73 to 46.8
Stroke
3/4"
Body Pattern
Two-way (stem up to open), three-way mixing (stem up to open B-AB)
Flow Characteristic
Two-way V5011N1xxx: equal percentage;
Two-way V5011N2xxx: linear;
Three-way: ports A-AB equal percentage, ports B-AB linear
Rangeability
50:1 per VDI/VDE 2173
Leakage Rating
ANSI Class III, 0.05% of Cv
Life Expectancy
250,000 full cycles at maximum rated temperature
Maximum Closeoff Pressure
Actuator dependant, see Selection Chart; maximum differential pressure for quiet service 20 psid
Pressure Drop
Maximum water differential pressure for quiet service 20 psid (138 kPa).
Maximum Pressure Rating
Water: 217 psi (1497 kPa) from 36° to 248℉ (2° to 120℃), 185 psi (1277 kPa) from 248° to 337℉ (120° to 169℃);
Steam: 100 psi (690 kPa) at 337℉ (169℃), using stainless trim valve (V5011N2xxx)
Pressure Rating
ANSI 150
Materials Of Construction
Red brass body, stainless steel stem, metal-to-metal brass/stainless plug and seat, spring-loaded carbon-fiber reinforced Teflon® V-ring packing
Media Compatibility
Hot or chilled water, <50% glycol, steam (use V5011N2xxx for steam above 15 psig (103 kPa) to 100 psig (690 kPa))
Media Temperature Range
Brass trim: 36° to 248℉ (2° to 120℃), 15 psig (103 kPa) steam;
Stainless trim: 36° to 340℉ (2° to 177℃), 100 psig (690 kPa) steam
Action
Stem up to open (2-way), stem up to open B-AB, close A-AB (3-way)
Compatible Actuators
Electric rotary Kele KA/KAS Series or Honeywell MN/MS Series with appropriate Q5020 Linkage, or direct-mount ML Series shown on following pages. For pneumatic actuation see MP953 Series in PNEUMATICS & FITTINGS catalog section.
Actuator Mounting
U-bolt or set screws to fit 1-3/8" valve yoke diameter, 3/4" stroke length
Operating Temperature
Actuator dependant, refer to appropriate ACTUATORS & DAMPERS section or ML Series (on following pages) for specifications
Approvals
Actuator dependant, refer to appropriate ACTUATORS & DAMPERS section or ML Series (on following pages) for specifications
Warranty
1 year on valves, 5 years on rotary actuators, 1 year on direct-mount actuators
product family features
- Two- and three-way body patterns from 1/2" to 2"
- Two-way equal percentage characteristics
- Three-way linear characteristics
- Floating, two-position, or proportional control actuators
- ANSI 150 body class
- Compatible with MP953 pneumatic actuators
more information & related documents
Family Description
The Kele V5011 Series is a two-way threaded globe valve used for control of water or steam. The V5013 Series is a three-way threaded globe valve used for mixing control of water. The valves can be ordered assembled with actuators for spring return or non-spring return operation, or the valve, linkage, and actuator may be ordered separately for field assembly.
