ARB24-3 | Belimo | Control Valves
Valve Actuator, Non-Spring, 24V, On/Off/Floating Point
Manufacturer:Belimo
MPN:ARB24-3
SKU:ARB24-3
List Price:
$510.55
Today's Price:
$285.91
product specifications
Actuator Series
ARB(X)
Agency Listings
cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, CE acc. to 2004/108/EC
Ambient Temperature Range
-22°F to 122°F [-30°C to 50°C]
Angle of Rotation
90°
Application Type
Water
Control
On/Off, Floating Point
Control Type
On/Off/Floating Point
Description
Valve Actuator, Non-Spring, 24V, On/Off/Floating Point
Direction of Rotation (Motor)
reversible with built-in switch
Electrical Connection
3 ft [1 m], 18 GA plenum cable with 1/2” conduit connector
Fail-Safe
Non-Spring Return
Housing
NEMA 2, IP54, UL enclosure type 2
Input Impedance
600 Ω
Manual Override
external push button
Noise Level (Motor)
<45 dB (A)
Position Indication
integrated into handle
Power Consumption Holding
0.5 W
Power Consumption Running
2.5 W
Power Supply
24 VAC ± 20%, 50/60 Hz, 24 VDC ± 10%
Power Supply Type
24V
Product family
Valve Actuator
Quality Standard
ISO 9001
Running Time
90 seconds
Running Time (Motor)
90 sec
Servicing
maintenance free
Storage Temperature Range
-40°F to 176°F [-40°C to 80°C]
Transformer Sizing
5.5 VA (class 2 power source)
Unit of Measure
PC
product family features
more information & related documents
Family Description
The B2 Series 2-way ball valves and B3 Series 3-way ball valves are used for two-position, floating or proportional control of HVAC hot or chilled water. Perfect for HVAC applications and Building Automation Systems, BAS, each two-way and three-way ball valve comes assembled with direct-coupled Belimo electric actuators with spring return or non-spring return operation.
Kele Description
180 IN-LB NSR 24VAC/VDC TRI-STATE
Manufacturer
Belimo
