250SMA11-AA11-BB21A0-NAT-R | Honeywell | Combustion Control & Flame Safety
HW MAX 2.5" NPT N/C SAFETY SHUTOFF VALVE: AUTO, VOS1/VCS1 SWITCHES, TRIM PKG 1, 40 PSI MOPD
Brand:Honeywell
MPN:250SMA11-AA11-BB21A0-NAT-R
SKU:250SMA11-AA11-BB21A0-NAT-R
List Price:
$8,136.00
Today's Price:
$4,230.72
Log in for customized pricing1 in stock
product series features
- 3/4" to 6" line sizes; Line pressures up to 125 PSIG
- Visual position indication standard
- Normally closed shutoff valves and normally open vent valves available
- Overtravel position switches for open and closed position
- General purpse approval standard; Also available with hazardous location approvals for use in non-incendive Class 1, Div 2 areas
- Electrically actuated valves with powerful closing spring provide closure in less than one second
- Designed to meet Fluid Control Institute (FCI) 70-2 control valve standard for Class VI seat leakage
- FM, CSA, UL, and CE approved; Full assessment to IEC 61508 as SIL 3 capable
more information & related documents
Series Description
<p>Honeywell Maxon electromechanical safety valves shut off gas lines in less than one second. All shut-off valves come equipped with Maxon's long-lasting metal-to-metal seating. A variety of optional body materials and body connections provide reliable operation even for highly corrosive fuels and for oxygen.<br></p><p>Application flexibility is provided with 3/4" through 6" diameter line sizes, Cv flow factors up to 1230, and line pressures up to 125 PSIG (8.6 bar)</p><p></p>
Kele Description
HW MAX 2.5" NPT N/C SAFETY SHUTOFF VALVE: AUTO, VOS1/VCS1 SWITCHES, TRIM PKG 1, 40 PSI MOPD
Manufacturer
Honeywell
Honeywell-Maxon-Gas-EM-Valves-Assemblies-Parts-2013
