Wall-mounted display with digital temperature and humidity readings.

SRMDDWRTDBT | Setra | Alarms & Indication

Room Pressure Double Monitor, White Bezel, Top Display Red Color, Temperature Measurement (14 to 140°F) (Top), SRH Duct Mount SRH12PD2CT5N, Bottom Display Blue Color, Temperature Measurement (14 to 140°F) (Bottom)

Brand:Setra

MPN:SRMDDWRTDBT

SKU:SRMDDWRTDBT

List Price:

$2,530.91

Today's Price:

$1,316.08

product datasheet

installation instructions

catalog page

Lead time of 10 days. Chat with Kele experts now

product specifications

Type

Room Temp Monitor

Display

LCD

Supply Voltage (Nominal)

24 VAC,24 VDC

Mount

Wall

product series specifications

Supply Voltage: 15-32 VDC or 24 VAC

Supply Watts: 50mA max (per display)

Accuracy: ±1% FS ±2 Counts

Operating Humidity: 5 to 95% RH (non-condensing)

Operating Temperature: 14° to 122°F (-10° to 50°C)

Enclosure Rating: Fire Retardant UL94V-0

Wiring Terminations: Screw Terminals

Dimensions: 5.8‚"H x 5.8" W x 1.25" (14.7 x 14.7 x 31.4 cm)

Approvals: CE

Weight: 0.8 lb (0.37 kg)

Warranty: 1 year

product series features

Highly visible 1 in. LCD display
Single LCD display or dual LCD display model
Available in red, green or blue LCD backlight
Available with White or Metallic Bezel
Flush mount design
Wipe down capable
Mount in standard 4-11/16 in. sq. electrical box
Compatible with any analog sensor with 0-5VDC or 0-10VDC output

more information & related documents

Series Description

The Setra SRMD Model's temperature and humidity display panel features a CE compliant, high visible, large 1 inch 3.5 digit LCD display and an attractive flush mounted faceplate bezel. This display panel is compatible with any temperature, humidity, CO2 sensor that has a 0 to 5 VDC or 0 to 10 VDC analog output.

Kele Description

DUAL RM MON, WHT BEZEL, RED/BLUE, DUCT, TEMP/TEMP

Manufacturer

Setra
