M6194D1017/U | Honeywell | Actuators & Dampers

List Price:

Today's Price:

product specifications

Supply Va

15 VA

Torque

300 in-lb

Supply Voltage (Nominal)

24 VAC

Control Signal

Floating

Dead weight load on shaft:

Power or auxiliary end: 200 lb (90.8 kg) max

Max combined load: 300 lb (136 kg)

Ambient temp: Max: 150°F (66°C) @ 25% duty cycle; Min: -40°F (-40°C)

Crankshaft: 3/8" (0.95 cm) square, dual-ended shaft

Agency approvals: UL listed, CSA, CE Guide #400-E

Warranty: 2 years

Signals: Model-specific Floating, proportional or 2-position

Series Description

Honeywell Modutrol motors are offered with a number of diffrent control signals for both damper and valve applications.

Kele Description

ACT. FLOATING CTRL 300 LBS.IN.

Manufacturer

Honeywell
